Introduction

This section contains general information about this guide, the Extron XTP T HDMI
Transmitter and XTP R HDMI Receiver. Topics in this section include:
•
•
•
•
Guide Overview
This guide contains installation, operation, control, and reference information for the
XTP T HDMI Transmitter and XTP R HDMI Receiver.
In this guide, the terms "XTP T HDMI" and "transmitter" refer to the XTP T HDMI Transmitter.
The terms "XTP R HDMI" and "receiver" refer to the XTP R HDMI Receiver.
XTP T HDMI Transmitter and XTP R HDMI Receiver Description
The XTP T HDMI and XTP R HDMI send and receive video, audio, bidirectional
RS-232 and IR, and Ethernet signals over a shielded twisted pair cable. They are
HDCP-compliant and support 1080p @ 60 Hz Deep Color and 1920x1200 signals, and
embedded HD lossless audio formats. They work with Extron XTP devices in matrix or
point-to-point applications for signal distribution and long-distance transmission (up to
330 feet) between remote endpoints, using shielded twisted pair cable.
Either device can be powered locally or remotely through an Extron Power Injector or XTP
matrix switcher (see
Both devices can be controlled through Extron Simple Instruction Set (SIS) commands (see
SIS Configuration and Control
System Configuration Software
Guide Overview
XTP T HDMI Transmitter and XTP R HDMI Receiver Description
System Compatibility
Features
Power Connection
XTP T HDMI Transmitter and XTP R HDMI Receiver • Introduction
on page 12).
on page 19) or the XTP Configuration Software (see
on page 26).
