— Total dropped packets for the current source since playback of
•
Dropped Packets:
the stream started.
• — Total percentage of dropped packets for the current source since
Dropped %:
playback of the stream started.
• — For transport streams, audio and video streams are combined for this
Jitter:
value.
• — For elementary streams, the audio stream jitter in milliseconds.
Audio Jitter:
• — For elementary streams, the video stream jitter in milliseconds.
Video Jitter:
The data in all current stream catagories resets automatically when a new stream is selected
or when play stops.
The panel displays a running total of raw network statistics from the interface for all
Total
streams, files, or clips played since the last manual reset including:
• — Always zero for full duplex links.
Collisions:
• — Receive data statistics.
Rx_Bytes:
• — Receive data statistics.
Rx_dropped:
• — Receive data statistics.
Rx_errors:
— Receive data statistics.
•
Rx_packets:
• — Transmit data statistics.
Tx_Bytes:
• — Transmit data statistics.
Tx_dropped:
• — Transmit data statistics.
Tx_errors:
• — Transmit data statistics.
Tx_packets:
Press to return the values in the
Reset Totals
monitoring begins automatically after each reset.
Device Status panel
Device Status panel — Monitors general operating conditions including:
• — Operating or standby.
Power Mode:
— Current internal temperature of the device. Readings above 60°C
•
Temperature:
could indicate excessive ambient termperature or insufficient ventilation and should be
investigated.
• — A general indication of the device workload.
Processor Usage:
• — Provides an indication of volatiile memory usage. It is typically 15%
Memory Usage:
after a power cycle, and expected to approach 100% after playing large clips from
shared network folders.
•
Up Time (operating) Hours:
SMD 101 was powered up or reset.
Local Storage panel
The Local Storage panel provides about the user accessible non-volatile storage including:
• — Internal
Type
• — User Content (can not be changed)
Name
• — Total size of the internal non-volatile storage in megabytes.
Total
• — Size of the files currently in local storage in megabytes.
Used
— Currently unallocated drive space.
•
Available
NOTE: plus
Used Available
requirements.
panel to zero. The information
Total
— The time in days, hours, and minutes since the
may not exactly add up to the
SMD 101 • Web-based User Interface
size due to system
Total
