Accepts 4:2:2 SDI in
NTSC and PAL standards
10 bit processing
Auto-detects input format
and de-serializes 270 Mbps
Auto input equalization
Re-clocked SDI input
loop-through
Simultaneous composite
and S-video outputs,
third output available as
component video or RGB
RGB or Betacam output
SDI-AVR 100 – SDI
A
V
C
TO
NALOG
IDEO
ONVERTER
NTSC or PAL color
bar test pattern
Rack mountable enclosure
Internal power supply
Advertisement
Related Manuals for Extron electronics SDI to Analog Video Converter SDI-AVR 100
Summary of Contents for Extron electronics SDI to Analog Video Converter SDI-AVR 100
- Page 1 Accepts 4:2:2 SDI in NTSC and PAL standards 10 bit processing Auto-detects input format and de-serializes 270 Mbps Auto input equalization Re-clocked SDI input loop-through Simultaneous composite and S-video outputs, third output available as component video or RGB RGB or Betacam output SDI-AVR 100 –...
- Page 2 ESCRIPTION The Extron SDI-AVR 100 is a 10 bit Serial Digital Interface (SDI) to analog video signal converter. The SDI-AVR 100 is ideal for A/V systems that use a mix of analog and SDI sources and helps integrate SDI sources into an analog video environment.
