— The MAC address of the connected SMD 101. The address is also
•
MAC Address:
available on the rear panel label.
• — Resets all network configuration to default.
Reset to Default:
• — Saves manual network configuration changes.
Save
• — Discards manual network configuration changes.
Cancel
NOTES:
• The DHCP assigned Gateway and DNS address are retained after DHCP is
deselected. They are reset using the reset button on the rear panel (see
Rear Panel Reset
Reset Device on page 42).
•
The network interface restarts when changes are saved.
Ethernet Diagnostics panel
This panel provides a ping utility for troubleshooting network connection issues.
• — Enter an IP address (10.13.193.168) or a complete host name
Address to ping:
(www.extron.com) in this field, then click
results of the ping opens.
Figure 32. Network Ping Dialog
Network Port Mapping panel
This panel provides basic Ethernet configuration that includes:
— Set the port number for SFTP here. Check
•
SFTP:
• — SSH provides a method for a SSH client to establish a secure
SIS (SSH):
connection to the player at port 22023, which then supports the SIS command set.
•
Telnet (Extron SIS):
access the SMD 101. Check
— Set the port number for HTTP here. Check
•
HTTP:
• — Set the port number for SNMP here. Check
SNMP:
• — Set the port number for HTTPS here. Check
HTTPS/SSL:
NOTE: Changing or disabling this port while using the default port (80) causes a
loss of the connection. Try https://<SMD101 IP> to reconnect to port 443.
• -
Serial Pass through:
here. Check to use the port.
Enable
• — Click to return all port mappings to default.
Reset to Default
Default port numbers are shown in
the port number field to enable the port entry in the associated port field. Click
return the port number to default.
on page 12) or using the web-based user interface (see
to start the utility. A dialog box with the
Ping
— The port used by DataViewer or other telnet programs to
to use the port.
Enable
— Set the port number for the serial pass-through feature
figure 31
on the previous page. Click the checkbox after
SMD 101 • Web-based User Interface
SMD 101
www.extron.com
192.168.3.51
to use the port.
Enable
to use the port.
Enable
to use the port.
Enable
to use the port.
Enable
Reset
to
35
