http:192.168.254.254/web/extron.sdp
4.
Add the SME 100 user name and password.
http://admin:123456@192.168.254.254/web/extron.sdp
5.
Press <Enter> to load the stream.
The stream loads. If Load Play is active, the stream begins playing. If Load Play is not active,
press play (see
Player Controls
Use the templates below to connect the SMD 101 player to SME 100 encoder streams.
Substitute the SME 100 IP address for
PULL Streaming:
URL
RTSP Unicast
RTSP://<
RTSP Multicast RTSP://<
or
HTTP://<
Table 1. Pull Stream URLs
PUSH Streaming:
Unicast
TS/UDP
TS/RTP
ES/RTP
Multicast (<DESTINATION IP> address must be the multicast IP address)
TS/UDP
TS/RTP
ES/RTP
Table 2. Push Stream URLs
NOTES:
•
<SME100_IP> is the IP address of the SME 100 encoder.
•
UDP and RTP DESTINATION_PORT default is 60000.
•
For ES/RTP, SAP is available in "Video only" stream mode.
on page 16) to play the stream.
.
<SME100_IP>
>/extron
SME100_IP
>/extron
SME100_IP
>/web/multicast.sdp
SME100_IP
UDP://@:<DESTINATION_PORT>
RTP://@:<DESTINATION_PORT>
HTTP://<SME100_IP>/web/output1.sdp
UDP://@<DESTINATION_IP>:<DESTINATION_PORT>
RTP://@<DESTINATION_IP>:<DESTINATION_PORT>
HTTP://<
>/web/output1.sdp
SME100_IP
SMD 101 • Advanced Player Configuration
55
