IR IN — Connect a remote IR receiver to this 3-pole 3.5 mm captive screw connector
D
to extend the range of the hand control.
From SMD 101
IR Receiver
+
S
G
Figure 6. IR In Wiring
RS-232 connector (optional) — Connect a host computer or control system to the
E
RS-232 connector or to the local device if pass-through mode is used. Use this port to
send SIS commands to the SMD 101 for device configuration and control. The default
protocol for this port is 9600 baud rate, no parity bit, 8 data bits, 1 stop bit, and no flow
control (handshaking).
For information on SIS commands, see
•
page 57.
See figure 7 below, to wire the RS-232 connector.
•
Connected RS-232
Device Pins
Receive
Transmit
Ground
Figure 7. RS-232 Connector Wiring
Reset button and LED — The reset button is used to return the SMD 101 to partial
F
or complete factory condition. The reset LED provides the status of the reset. The
SMD 101 has three reset modes (see
page).
RJ-45 LAN connector — Connect one end of an RJ-45 cable to the LAN (Ethernet)
G
connector on the SMD 101 (see figure 8). Connect the other end of the RJ-45 cable to
a router or switch to connect the SMD 101 to a network.
LAN
ACT LINK
Figure 8. RJ-45 Ethernet Connector
The LEDs on the Ethernet connector indicate the status of the network connection.
Link LED — This green LED lights when the SMD 101 is properly connected to an
•
active network.
Act LED — This amber LED blinks in a pattern to indicate the connected network
•
speed as follows:
Three blinks — 1 Gbps
•
Two blinks — 100 Mbps
•
One blink — 10 Mbps
•
IR IN
Remote Communication and Control
SMD 101
Pins
Tx
Rx
G
SMD 101 Rear Panel Reset
SMD 101 • Panels and Cabling
on
on the following
11
