Filter
Filters are provided to refine the list of streams viewed in the browser. There are three filters
with sub-filters to narrow the list of streams. The default choice for each filter is
Source — Limits the browser to streams identified by their source device or location.
•
The drop-down list is populated with SAP source identification data. Limiting choices
are
Extron
NOTE: A stream listed under Extron is defined as a member of the Extron group by
the SAP/SDP message. If the SAP/SDP message does not indicate Extron group
membership, it is listed in Other.
•
Protocol — Limits the browser to streams identified by their transport protocol (UDP or
RTP). The list is dynamic, populated from SAP transport protocol data as the streams
are identified.
•
Addressing — Limits the browser list to streams identified as unicast or as multicast.
NOTE: Unicast streams can only be played if the connection (destination)
address is set correctly at the decoder.
Load
Loads the selected stream for playing.
Browser Panel - Files
The
Files
storage (up to 175 MB for user content) and shared network folders (when mounted). Each
file type (audio, image, video, system, and playlist) has a different icon to distinguish it.
Figure 17.
Separate controls fully expand, fully collapse, or refresh the list. In addition, click the
corresponding individual folder icons to expand or collapse.
or
.
Other
tab opens a list of available clips and playlists in the file system including internal
Browser Panel, Files
SMD 101 • Web-based User Interface
.
All
20
