Barco BARCOREALITY SIM 6 ULTRA R9040150 Owner's Manual

Barco BARCOREALITY SIM 6 ULTRA R9040150 Owner's Manual

Barcoreality sim 6 ultra
Hide thumbs Also See for BARCOREALITY SIM 6 ULTRA R9040150:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
S
P
IMULATION
RODUCTS
B
R
SIM 6 ULTRA
ARCO
EALITY
R9040150
R9040151
O
'
M
WNER
S
ANUAL
14052003
R5976420/03

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BARCOREALITY SIM 6 ULTRA R9040150 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Barco BARCOREALITY SIM 6 ULTRA R9040150

Summary of Contents for Barco BARCOREALITY SIM 6 ULTRA R9040150

  • Page 1 IMULATION RODUCTS SIM 6 ULTRA ARCO EALITY R9040150 R9040151 ’ WNER ANUAL 14052003 R5976420/03...
  • Page 2 Barco nv Simulation Products 600 Bellbrook Ave, Xenia OH 45385 Phone: +1 (937) 372 7579 Fax: +1 (937) 372 8645 E-mail: eis@barco.com Visit us at the web: www.eis.barco.com Barco nv Simulation Products Noordlaan 5, B-8520 Kuurne Phone: +32 56.36.82.11 Fax: +32 56.36.84.86 E-mail: info@barco.com...
  • Page 3 Changes Barco provides this manual ’as is’ without warranty of any kind, either expressed or implied, including but not limited to the implied war- ranties or merchantability and fitness for a particular purpose. Barco may make improvements and/or changes to the product(s) and/or the program(s) described in this publication at any time without notice.

  • Page 5: Table Of Contents

    Table of contents TABLE OF CONTENTS 1. Packaging and Dimensions ..................5 Lens Packaging .
  • Page 6 Table of contents 5.4.6.1 Starting Up Windowing ....................52 5.4.6.2 Blanking (Windowing).
  • Page 7 Barco logo ........
  • Page 8 Table of contents R5976420 BARCOREALITY SIM 6 ULTRA 14052003...

  • Page 9: Packaging And Dimensions

    1. Packaging and Dimensions 1. PACKAGING AND DIMENSIONS This chapter handles about the way the projector is packed and gives an overview of the dimensions. • Lens Packaging • Dimensions 1.1 Lens Packaging Way of Packaging Lenses are supplied as an individual item. They are packed in a carton box.
  • Page 10 1. Packaging and Dimensions 82.7 211.4 169.5 139.6 148.9 380.6 526.8 Image 1-2 Side view dimensions projector Image 1-3 Top view dimensions projector R5976420 BARCOREALITY SIM 6 ULTRA 14052003...

  • Page 11: Installation Guidelines

    2. Installation Guidelines 2. INSTALLATION GUIDELINES Overview • Installation guidelines • Configuration • Lenses • Batteries Before installing the projector, read first the safety instructions supplied with the BARCOREALITY SIM6 UL- TRA. 2.1 Installation guidelines Ambient Temperature Conditions Careful consideration of things such as image size, ambient light level, projector placement and type of screen to use are critical to the optimum use of the projection system.

  • Page 12: Configuration

    2. Installation Guidelines is also important. Too much ambient light will ‘wash out’ of the projected image. This appears as less contrast between the darkest and lightest parts of the image. With bigger screens, the ‘wash out’ becomes more important. As a general rule, darken the room to the point where there is just sufficient light to read or write comfortably.

  • Page 13: Lenses

    2. Installation Guidelines SIDE VIEW CD = B - A Screen Projector Optical axis projection lens Floor Screen TOP VIEW Floor BACK VIEW Image 2-1 Distance between ceiling and top of the screen or between floor and bottom of the screen. Correction value, distance between bottom side of projector (without feet) and middle of the lens.

  • Page 14: Lenses

    2. Installation Guidelines 2.3.1 Lenses Available lenses The following lenses are available, or will become available (contact a BARCO service center) as an option : Lenses Standard version Scheimpflug version QFD(1.27:1) R9840400 R9840600 QFD(2.5:1) R9840290 R9840470 QFD(1.4-2.1:1) R9840380 R9840610 QFD(2.1-3.0:1)

  • Page 15: Lens Installation

    2. Installation Guidelines Lens program calculate projector distance available BARCO site http://www.barco.com/projection_systems/customer_services/lens_program.asp 2.3.3 Lens installation How to install ? Follow the next procedure : 1. Open the lens cover of the projector by pivoting it up and take it off. (image 2-2) 2.

  • Page 16: Cleaning The Lens

    2. Installation Guidelines 2.3.4 Cleaning the lens To minimize the possibility of damaging the optical coating or scratching exposed lens surface, we have de- veloped recommendations for cleaning the lens. FIRST, we recommend you try to remove any material from the lens by blowing it off with clean, dry deionized air.

  • Page 17: Connections

    3. Connections 3. CONNECTIONS Overview • Power connections • Switching on • Switching to standby • Switching off • Source Specifications • Input source connections • Communications connections 3.1 Power connections AC Power cord connection Use the supplied power cord to connect your projector to the wall outlet. Plug the female power connector into the male connector at the front of the projector.
  • Page 18 The total lifetime of the lamp for a safe operation is “x” hours max, do not use it longer. Always replace with a same type of lamp. Call a BARCO authorized service technician for lamp replacement. Press ENTER to reset the lamp runtime.

  • Page 19: Switching To Standby

    3. Connections Max Lamp runtimes for the available projectors. SIM Projector x (Max lamp runtime, in hours) BARCOREALITY SIM6 ULTRA 1000 Using a lamp for more than its recommended life time is dangerous as the lamp could explode. 3.3 Switching to standby How to switch to standby? 1.

  • Page 20: Input Source Connections

    3. Connections Recommended source specifications: • The Active number of pixels has to be 1024 x 768 (XGA), 1280 x 1024 (SXGA) or 1600 x 1200 (UXGA). 3.6 Input source connections 3.6.1 Input facilities Overview Input Facilities 10/100 Base-T RS232 IN RS232 OUT COMM.

  • Page 21: Inputs Via Rcvds05

    Select a path from below : Select a path from below : INPUT SLOTS INPUT SLOTS RANDOM ACCESS RANDOM ACCESS NO SIGNAL NO SIGNAL INSTALLATION INSTALLATION BARCO LOGO BARCO LOGO SERVICE SERVICE LENS LENS MENU POSITION[CENTER] MENU POSITION[CENTER] 800 PERIPHERAL 800 PERIPHERAL MORE ...
  • Page 22 3. Connections How to connect to Input 1? 1. Connect the Output of the Image Generator to the 5–Cable BNC Input (Input 1) on the projector. (image 3-5) 10/100 Base-T RS232 IN RS232 OUT COMM. PORT VIDEO S-VIDEO IEEE 1394 MOUSE MONITOR AUDIO IN...

  • Page 23: Input 2

    Select a path from below : Select a path from below : SLOT SELECTOR [AUTOMATIC] RANDOM ACCESS RANDOM ACCESS NO SIGNAL INSTALLATION INSTALLATION BARCO LOGO x 1. RGB [HS&VS] SERVICE SERVICE LENS - 2. RGB [HS&VS] MENU POSITION[CENTER] - 3. NO MODULE 800 PERIPHERAL - 4.

  • Page 24: Input 3 (Optional)

    3. Connections RS232 IN COMM. PORT VIDEO S-VIDEO IEEE 1394 MOUSE 10/100 Base-T RS232 OUT MONITOR AUDIO IN AUDIO IN AUDIO IN AUDIO IN COMPUTER Computer Image 3-6 Connecting to Input 2 Pin configuration of the D15 connector GREEN BLUE loop through to monitor ground ground...

  • Page 25: Input 4 (Optional)

    3. Connections Video Composite Video is a single video signal that contains luminance, color and synchronization information. NTSC, PAL and SECAM are examples of composite video systems. What can be connected to the Video Input? Composite video signals from a VCR, OFF air signal decoder, ... Loop through is not available.

  • Page 26: Communications Connections

    3. Connections How to connect a Super Video Source to the projector? 1. Connect the Output of the Super Video Source to the Super Video Input (Input 4) on the projector. (image 3-8) S-VHS Source Luma/Chroma COMM. PORT MOUSE 10/100 Base-T RS232 IN RS232 OUT VIDEO...

  • Page 27: Getting Started

    4. Getting started 4. GETTING STARTED 4.1 RCU & Local keypad How controlling the projector ? The projector can be controlled by the local keypad or by the remote control unit. Location of the local keypad ? The local keypad is located on the backside of the projector. Remote control functions.
  • Page 28 4. Getting started EXIT ENTER PAUSE TEXT PHASE SHARPN TINT COLOR BRIGHTN CONTR TREBLE BALANCE BASS Image 4-1 RCU function indication Function keys not used. ADJ. exit all menu’s. Address key (recessed key), to enter the address of the projector (between 0 and 9). Press the recessed address key with a pencil, followed by pressing one digit button between 0 and 9.

  • Page 29: Operating The Projector

    4. Getting started TEXT when adjusting one of the image, e.g. controls during a meeting, the displayed bar scale can be removed by pressing ’TEXT’ key first. To re-display the bar scale on the screen, press ’TEXT’ key again. ENTER to start up the adjustment mode or to confirm an adjustment or selection in the adjustment mode.

  • Page 30: Quick Setup Adjustments

    4. Getting started Stand-by key EXIT ENTER PAUSE TEXT STANDBY EXIT ENTER PHASE TEXT PAUSE SHARPN TINT SHARPN BRIGHTN TINT PHASE COLOR CONTRAST COLOR BRIGHTN CONTR TREBLE BALANCE BASS Image 4-3 4.4 Quick setup adjustments Overview • Quick lens Adjustment •...

  • Page 31: Quick On Screen Color Change

    4. Getting started WARNING LENS-LOCKING IS ACTIVATED ADJUSTING THE LENS MAY DAMAGE THE PROJECTOR PRESS * TO ADJUST <EXIT> to return Menu 4-1 Quick zoom/focus adjustment 1. Press the Selection key *. The zoom/focus menu will be displayed. 2. Push the cursor key ↑ or ↓ to zoom and ← or → to focus the image. 3.

  • Page 32: Using The Rcu

    4. Getting started 4.5 Using the RCU Pointing to the reflective screen 1. Point the front of the RCU to the reflective screen surface. (image 4-4) Ceiling Screen IR sensor Image 4-4 Pointing the RCU via the screen to the IR sensor Hardwired Remote Input 1.

  • Page 33: Directly To One Of The Ir Sensors Of The Projector

    4. Getting started RS232 IN COMM. PORT VIDEO S-VIDEO IEEE 1394 MOUSE RS232 OUT 10/100 Base-T COMPUTER MONITOR AUDIO IN AUDIO IN AUDIO IN AUDIO IN Image 4-5 RCU Hardwired to Remote Input Directly to one of the IR sensors of the projector. When using the wireless remote control, make sure you are within the effective operating distance (30m, 100ft in a straight line).

  • Page 34: Projector Address

    4. Getting started VIDEO S-VIDEO IEEE 1394 TRIG MOUSE RS232 IN RS232 OUT COMM. PORT COMPUTER MONITOR AUDIO IN AUDIO IN AUDIO IN AUDIO IN 45ø 45ø 45ø 45ø EXIT EXIT ENTER ENTER PAUSE TEXT PAUSE TEXT PHASE PHASE SHARPN SHARPN TINT TINT...

  • Page 35: Displaying And Programming Addresses

    4. Getting started A projector will respond to a RCU set to the common address (’0’ or ’1’) regardless of what address is set in the projector itself. The RCU is default programmed with address 0 or 1, ’common address’. With that ’common address’ pro- grammed into the RCU, every projector, without exception will listen to the commands given by this RCU.

  • Page 36: The Pause Key

    4. Getting started Tint Tint is only active for Video and S-Video when using the NTSC 4.43 or NTSC 3.58 system. Use the + button Use the - button. Sharpness Use the + button for a sharper picture. Use the - button for a softer picture. Phase Use the + or - button to adjust the phase.

  • Page 37: Random Access

    5. Random Access 5. RANDOM ACCESS Overview • Random Access Overview • Random Access Start up • File Service • Picture Tuning • Geometry • Geometry R5976420 BARCOREALITY SIM 6 ULTRA 14052003...

  • Page 38: Random Access Overview

    5. Random Access 5.1 Random Access Overview Random Access Overview • File Service Load Edit Rename Copy Delete Options File Sort [Name/Index] File Load [Automatic/Manual] Serial File Load [On/Off] Field Stretch [Off] • Picture Tuning Motion Compensation (Optional) LCD Speed LCD Speed R/G LCD Speed B/G Color Temperature...

  • Page 39: Random Access Start Up

    5. Random Access • Geometry (When the WARP 6™ option is activated) Load Edit Coarse Linearity Fine Shift Transport Delay Mode [Automatic/Manual] Transport Delay Setting Blanking/Soft Edge (Optional) Active [On/Off] Blanking Soft Edge Width (Optional) Reset Coarse Linearity Fine Blanking/Soft Edge (Optional) Soft Edge (Optional) Rename Copy...

  • Page 40: Possible File Manipulations

    5. Random Access Take the following notation : xxxxxxxx.eee n ppppXppppi xxxxxxxx base name, 8 characters file extension first character C : custom made file first character S : standard file The second and third character is used for a following number (= file index).

  • Page 41: Load File

    5. Random Access 5.3.4 Load File Start up Load file To start up the load file, handle as follow : 1. Push the cursor key ↑ or ↓ to highlight Load. (menu 5-4) 2. Press ENTER to select. The Load menu displays the corresponding files depending on the installed filter. (menu 5-5) FILE SERVICE LOAD FILE FILTER LIST [All]...

  • Page 42: Edit File

    5. Random Access 5.3.5 Edit file The Edit file menu makes it possible to change the settings of the file according to the real settings of the connected source. Consult the source specification before entering the data. • Start up •...

  • Page 43: Correct Value

    5. Random Access How to change a setting with the cursor keys and counting up or down? 1. Push the cursor key ↑ or ↓ to highlight an item. The color of the selected item will change. 2. Press ENTER to activate. 3.
  • Page 44 5. Random Access How to install the correct settings for the options in the Edit file menu. EDIT FILE OPTIONS Source number Clamp delay Clamp width Field polarity [pos] Select with ↑ or ↓ <ENTER> to toggle ↑ or ↓ to change value <EXIT>...

  • Page 45: Rename

    5. Random Access 5.3.5.4 Rename Start Up To change the name of a selected file : 1. Push the cursor key ↑ or ↓ to highlight Rename. (menu 5-12) 2. Press ENTER. The Rename selection menu will be displayed. (menu 5-13) 3.

  • Page 46: Copy

    5. Random Access 5.3.5.5 Copy Start Up To copy the name of a selected file : 1. Push the cursor key ↑ or ↓ to highlight Copy. (menu 5-15) 2. Press ENTER. The Copy selection menu will be displayed. (menu 5-16) 3.

  • Page 47: File Options

    5. Random Access 4. Press ENTER to select. If [all] is selected, your password has to be entered before all files will be deleted. A confirmation menu "Delete file name ?" is displayed. (menu 5-20) 5. Press ENTER to delete the file, press EXIT if you want to keep it. Note: The active file cannot be deleted.

  • Page 48: File Load

    5. Random Access File Load 1. Push the cursor key ↑ or ↓ to highlight File Load. (menu 5-24) 2. Press ENTER to toggle between [AUTOMATIC] or [MANUAL]. This File Load setting is default set to [AUTOMATIC]. [AUTOMATIC] The projector will automatically load the file that is best suited for the selected Input Slot. [MANUAL] The user will select and load the desired file.

  • Page 49: Picture Tuning

    5. Random Access 5.4 Picture Tuning 5.4.1 Starting up Picture Tuning How to start up ? 1. Push the cursor key ↑ or ↓ to highlight Picture Tuning. (menu 5-26) 2. Press ENTER to select. The Picture Tuning menu will be displayed. (menu 5-27) RANDOM ACCESS PICTURE TUNING ADJUSTMENT MODE...

  • Page 50: Starting Up The Motion Compensation

    5. Random Access 5.4.2.1 Starting up the Motion Compensation How to start up ? 1. Push the cursor key ↑ or ↓ to highlight Motion compensation. (menu 5-28) 2. Press ENTER to select. The Motion Compensation menu will be displayed. (menu 5-29) PICTURE TUNING MOTION COMPENSATION MOTION COMPENSATION...

  • Page 51: Lcd Speed B/G

    5. Random Access How to set the Red LCD speed ? 1. Push the cursor key ↑ or ↓ to highlight LCD speed R/G. (menu 5-31) 2. Press ENTER to select. A sliderbow will be displayed 3. Push the cursor key ← or → to set the Red LCD speed. MOTION COMPENSATION LCD SPEED LCD SPEED R/G...

  • Page 52: Gamma

    5. Random Access How to start up ? 1. Push the cursor key ↑ or ↓ to highlight Color Temperature. (menu 5-33) 2. Press ENTER to select. The color temperature selection menu will be displayed. (menu 5-34) PICTURE TUNING COLOR TEMPERATURE MOTION COMPENSATION PROJECTOR WHITE COLOR TEMPERATURE...
  • Page 53 5. Random Access influence only the actual custom adjustment file. This procedure is not so easy and is best done or first demonstrated by an autho- rized Barco service technician. Step to be taken To adjust the input balance, the following steps have to be executed in the following order: The procedure is best done when using a source that can generate a full black and full white image.
  • Page 54 5. Random Access Image 5-3 Full black image on the source Image 5-4 Perfect Black Balance How to adjust the White Balance? 1. Generate a full white image on the source. (image 5-5) 2. Push the cursor key ↑ or ↓ to highlight White Balance and press ENTER to select. (menu 5-38) 3.
  • Page 55 5. Random Access Image 5-5 Full white image on the source Image 5-6 Perfect White Balance How to return to the Default factory preset? 1. Push the cursor key ↑ or ↓ to highlight Default and press ENTER to select. (menu 5-39) The input balance is set to the default factory preset.

  • Page 56: Windowing

    5. Random Access 5.4.6 Windowing 5.4.6.1 Starting Up Windowing How to Start Up the Windowing menu? 1. Push the cursor key ↑ or ↓ to highlight Windowing. (menu 5-40) 2. Press ENTER to select. The Windowing menu will be displayed. (menu 5-41) PICTURE TUNING WINDOWING MOTION COMPENSATION...
  • Page 57 5. Random Access TOP BLANKING Image 5-7 Top Blanking barscale Image 5-8 Blanking (Windowing) adjustment How to reset the Blanking adjustment(s)? 1. Push the cursor key ↑ or ↓ to highlight Reset. (menu 5-45) 2. Press ENTER to reset all blanking adjustments. BLANKING BOTTOM LEFT...

  • Page 58: Shift (Windowing)

    5. Random Access 5.4.6.3 Shift (Windowing) What can be done with Shift (Windowing)? With the Shift function it is possible to shift the image while keeping the pre-distorted WARP 6™ geometry settings of the image. How to Start Up the Shift adjustment? 1.

  • Page 59: Size (Windowing)

    5. Random Access Image 5-11 Vertical Shift (Windowing) adjustment 5.4.6.4 Size (Windowing) What can be done with Size (Windowing)? With the Size function it is possible to adjust the size of the image while keeping the pre-distorted WARP 6™ geometry settings of the image.

  • Page 60: Geo Soft Edge

    5. Random Access Image 5-14 Vertical Size adjustment 5.4.6.5 Geo Soft Edge What can be done with Geo Soft Edge? When setting up a soft edge (see Electronic Soft Edge), these setting are applied on all sources (source files). With the Geo Soft Edge toggle it is possible to disable the soft edge settings.

  • Page 61: Geometry

    5. Random Access How to change the Aspect Ratio? 1. Push the cursor key ↑ or ↓ to highlight Aspect Ratio. (menu 5-49) 2. Press ENTER to toggle between the available Aspect Ratio settings: [4:3] (Default for SIM 6 Ultra) [5:4] (Default for SIM 6 + WARP 6 and SIM 6 MKII + WARP 6) [16:9] WINDOWING...

  • Page 62: Geometry File Annotation

    5. Random Access How to start up ? 1. Push the cursor key ↑ or ↓ to highlight Geometry. (menu 5-50) 2. Press ENTER to select. The Geometry files menu will be displayed. (menu 5-51) RANDOM ACCESS GEOMETRY FILES ADJUSTMENT MODE LOAD FILE SERVICE EDIT...

  • Page 63: Load

    5. Random Access 5.5.6 Load How to start up ? To start up the Load File menu, handle as follow : 1. Push the cursor key ↑ or ↓ to highlight Load. (menu 5-52) 2. Press ENTER to select. The Load File menu will be displayed. (menu 5-53) GEOMETRY FILES LOAD FILE PREVIEW[OFF]...

  • Page 64: Edit

    5. Random Access 5.5.7 Edit Overview • Introduction • Start up • Coarse • Linearity adjustment • Fine • Shift • Transport Delay • Blanking • Electronic Soft Edge (Optional) • Reset R5976420 BARCOREALITY SIM 6 ULTRA 14052003...

  • Page 65: Introduction

    5. Random Access 5.5.7.1 Introduction How does it work ? • The projected image on the screen is divided in 81 zones. Each zone represents a grid point that can be shifted to the desired location. These grid points will interact on each other in a hierarchic way, adjusting a grid point on a certain hierarchic level will affect all grid points underneath.

  • Page 66: Start Up

    5. Random Access 5.5.7.2 Start up How to Start up the Edit mode ? 1. Push the cursor key ↑ or ↓ to highlight Edit in the Geometry Files menu. (menu 5-55) 2. Press ENTER to select. The Guided Geometry Map menu will be displayed. (menu 5-56) GEOMETRY FILES GUIDED GEOMETRY MAP LOAD...

  • Page 67: Corner Adjustment

    5. Random Access How to select the Corners ? 1. Push the cursor key ↑ or ↓ to highlight the Coarse selection. (menu 5-59) 2. By default corner is already selected, if not, press ENTER until corner is displayed. 3. Push the cursor key ← or → to select the desired Corner. The COL &...
  • Page 68 5. Random Access How to adjust the Corners ? 1. Push the cursor key ↑ or ↓ to select pixel x = 0 in the Geometry Distortion menu. (menu 5-60) 2. Push the cursor key ← or → to coarse shift the selected Corner in a horizontal way. (image 5-18) 3.

  • Page 69: Side Bow Selection

    5. Random Access Image 5-19 Corner pixel y adjustment Image 5-20 Keystone correction 5.5.7.3.4 Side Bow selection What can be done ? With the Coarse Side Bow selection it is possible to: • apply a bow shaped pre-distortion on the projected image. •...
  • Page 70 5. Random Access How to select the Side Bows ? 1. Push the cursor key ↑ or ↓ to highlight the Coarse selection. (menu 5-62) 2. Press ENTER to scroll through the available Coarse selections until side bow is displayed. (menu 5-63) 3.

  • Page 71: Bow Shaped Pre-Distortion Set Up

    5. Random Access 5.5.7.3.5 Bow shaped pre-distortion set up How to set up a bow shaped pre-distortion ? We assume side bow top is selected. 1. Push the cursor key ↑ or ↓ to select pixel y = 0 in the Geometry Distortion menu. (menu 5-64) 2.
  • Page 72 5. Random Access By pressing the * key on the RCU an internal hatch pattern is projected instead of the image data. How to perform a coarse linearity adjustment by using the Side Bows? We assume side bow top is selected. 1.

  • Page 73: Center Selection

    5. Random Access 5.5.7.3.7 Center selection What can be done ? With the Coarse Center selection it is possible to perform a coarse bow correction on the projected image. How to select the Center ? 1. Push the cursor key ↑ or ↓ to to highlight the Coarse selection. 2.

  • Page 74: Linearity Adjustment

    5. Random Access 5. Use the subpixel adjustments to fine shift the Center. 6. When the Coarse adjustment is finished press EXIT to return to the Guided Geometry Map menu. GEOMETRY DISTORTION GEOMETRY DISTORTION center center col = 4 col = 4 row = 4 row = 4 pixels x = 0...

  • Page 75: Horizontal Or Vertical Linearity Selection

    5. Random Access 5.5.7.4.2 Horizontal or Vertical Linearity selection What can be done with the Linearity adjustment ? Within this Linearity adjustment mode it is possible to perform a coarse correction of the horizontal and vertical nonlinearity. The Linearity adjustment is best done when a hatch pattern is projected on the screen. By pressing the * key on the RCU an internal hatch pattern is projected instead of the image data.
  • Page 76 5. Random Access Image 5-27 Horizontal Linearity coarse adjustment Image 5-28 Horizontal Linearity right adjustment Image 5-29 Horizontal Linearity center adjustment R5976420 BARCOREALITY SIM 6 ULTRA 14052003...

  • Page 77: Vertical Linearity Adjustment

    5. Random Access 5.5.7.4.4 Vertical Linearity adjustment How to adjust the Vertical Linearity ? A correct Vertical Linearity is achieved when the distances between the horizontal lines of the hatch pattern are equal or almost equal from top to bottom. 1.

  • Page 78: Fine

    5. Random Access Image 5-31 Vertical Linearity bottom adjustment Image 5-32 Vertical Linearity center adjustment 5.5.7.5 Fine Overview • Start up • Horizontal or Vertical Linearity selection • Fine Horizontal or Vertical Linearity adjustment • Bow Linearity selection • Bow Linearity adjustment •...

  • Page 79: Start Up

    5. Random Access 5.5.7.5.1 Start up How to Start up the Fine adjustment ? 1. Push the cursor key ↑ or ↓ to highlight Fine in the Edit menu. (menu 5-77) 2. Press ENTER to select. The Geometry Distortion menu will be displayed. (menu 5-78) GUIDED GEOMETRY MAP GEOMETRY DISTORTION COARSE...

  • Page 80: Fine Horizontal Or Vertical Linearity Adjustment

    5. Random Access Image 5-33 Fine horizontal or vertical linearity selections 5.5.7.5.3 Fine Horizontal or Vertical Linearity adjustment How to adjust the Fine Horizontal or Vertical Linearity ? We assume hor lin left top is selected. 1. Push the cursor key ↑ or ↓ to highlight pixel x = 0. (menu 5-80) 2.

  • Page 81: Bow Linearity Selection

    5. Random Access Image 5-34 Fine horizontal or vertical linearity adjustment 5.5.7.5.4 Bow Linearity selection What can be done ? Within this menu it is possible to perform a fine bow correction on the projected image. How to select the Bow Linearity ? 1.

  • Page 82: Bow Linearity Adjustment

    5. Random Access Image 5-35 Fine bow linearity selections 5.5.7.5.5 Bow Linearity adjustment How to adjust the Bow Linearity ? We assume bow top is selected. 1. Push the cursor key ↑ or ↓ to highlight pixel y = 0. (menu 5-83) 2.

  • Page 83: Quadrant Selection

    5. Random Access Image 5-36 Fine bow linearity adjustments 5.5.7.5.6 Quadrant selection What can be done ? Within this menu it is possible to perform a fine adjustment within a selected quadrant. How to select the Quadrants ? 1. Push the cursor key ↑ or ↓ to highlight the Fine selection. (menu 5-84) 2.

  • Page 84: Quadrant Adjustment

    5. Random Access Image 5-37 Fine quadrant selections 5.5.7.5.7 Quadrant adjustment How to adjust Quadrants ? We assume quadrant top left is selected. 1. Push the cursor key ↑ or ↓ to highlight pixel Y = 0. (menu 5-86) 2. Push the cursor key ← or → to shift the selected grid point in a vertical way. This will result in a fine adjustment within the selected quadrant (Follow this procedure in a similar way to apply a fine adjustment on any desired quadrant).

  • Page 85: Local Selection

    5. Random Access Image 5-38 Fine quadrant adjustments 5.5.7.5.8 Local selection What can be done ? Within this menu it is possible to smooth away bumps and irregularities within the selected local zone of the projected image. How to select the Local grid points ? 1.

  • Page 86: Local Adjustment

    5. Random Access Image 5-39 Fine local grid point selections 5.5.7.5.9 Local adjustment How to adjust the Local grid points ? 1. Push the cursor key ↑ or ↓ to select pixel x = 0 in the Geometry Distortion menu. (menu 5-90) 2.

  • Page 87: Shift

    5. Random Access 5.5.7.6 Shift What can be done with the Shift adjustment ? With Shift adjustment it is possible to shift the whole image. How to Start up Shift adjustment ? 1. Push the cursor key ↑ or ↓ to highlight Shift in the Edit menu. (menu 5-91) 2.
  • Page 88 5. Random Access Image 5-41 Transport Delay basic principle How to Start up the Transport Delay ? 1. Push the cursor key ↑ or ↓ to highlight Transport Delay in the Edit menu. (menu 5-95) 2. Press ENTER to select. The Transport Delay menu will be displayed.

  • Page 89: Blanking

    5. Random Access 7. Repeat step 3 to 6 for projector 3. 8. Press EXIT to return to the Guided Geometry Map menu. TRANSPORT DELAY TRANSPORT DELAY TRANSPORT DELAY TRANSPORT DELAY MODE [AUTOMATIC] MODE [MANUAL] MODE [AUTOMATIC] MODE [MANUAL] TRANSPORT DELAY = 168 TRANSPORT DELAY = 168 TRANSPORT DELAY = 168 TRANSPORT DELAY = 168...

  • Page 90: Blanking Active On

    5. Random Access 5.5.7.8.2 Blanking Active On How to switch Blanking Active On ? 1. Push the cursor key ↑ or ↓ to highlight Active in the Blanking/Soft Edge menu. (menu 5-103) 2. Press ENTER to switch Active [OFF] to [ON]. See menu 5-104.

  • Page 91: Blanking Adjustment

    5. Random Access Image 5-42 Shape selections 5.5.7.8.5 Blanking adjustment What is % of image and %% of image adjustment ? % of image Coarse adjustment, this will shift the blending zone in steps of 1/100 of the total image shape. %% of image Fine adjustment, this will shift the blending zone in steps of 1/10000 of the total image shape.

  • Page 92: Electronic Soft Edge (Optional)

    5. Random Access 5. Press EXIT to return to the Guided Geometry Map menu. 6. Press EXIT to return to the Edit menu. SHAPE top left % of image = 0 %% of image = 0 Menu 5-108 5.5.7.9 Electronic Soft Edge (Optional) Whenever Soft Edge is mentioned in this chapter this always refer to Electronic Soft Edge.

  • Page 93: Preparations

    5. Random Access Image 5-43 WhySoft Edge ? What is the Basic Principal of Soft Edge ? The principle of edge blending is archived by linear modulation of the light output in the overlap zone so that the light output in that zone equals the light output of the rest of the image.

  • Page 94: Soft Edge Start Up

    5. Random Access 5.5.7.9.3 Soft Edge Start up How to Start up Soft Edge ? 1. Push the cursor key ↑ or ↓ to highlight Blanking/Soft Edge menu. (menu 5-109) 2. Press ENTER to select. The Blanking/Soft Edge menu will be displayed. (menu 5-110) GUIDED GEOMETRY MAP BLANKING/SOFT EDGE COARSE...

  • Page 95: Soft Edge Shape Selections

    5. Random Access How to Start Up the Soft Edge Shape menu ? 1. Push the cursor key ↑ or ↓ to highlight Shape in the Blanking/Soft Edge menu. (menu 5-113) 2. Press ENTER to select. The Shape menu will be displayed. (menu 5-114) BLANKING/SOFT EDGE SHAPE ACTIVE [ON]...

  • Page 96: Basic Soft Edge Shape Set Up

    5. Random Access Image 5-45 Shape selections 5.5.7.9.7 Basic Soft Edge Shape Set up The following procedures will adjust the Shape of a basic Electronic Soft Edge set up with 2 projectors and a 12.5 % overlap zone, apply the same procedures for every Electronic Soft Edge you want to create in a multi-projector system.
  • Page 97 5. Random Access Setting up the Shape for Projector 1 1. Use the combination of ENTER and the cursor key ← or → to select right all. (menu 5-116) 2. Push the cursor key ↑ or ↓ to select % of image. (menu 5-117) 3.

  • Page 98: Soft Edge Width Start Up

    5. Random Access Image 5-48 Basic Shape set up for Projector 2 5.5.7.9.8 Soft Edge Width Start up When Soft Edge is not installed on the projector or when the Soft Edge Active mode is set to [OFF] this menu item will be grayed out.

  • Page 99: Basic Soft Edge Width Set Up

    5. Random Access Image 5-50 Soft Edge Width selections 5.5.7.9.10 Basic Soft Edge Width Set up Setting up the Width for Projector 1 ? 1. Press ENTER until Right is selected. (image 5-51) 2. Push the cursor key ← or → to adjust the right width until it matches or exceeds the width of the overlap zone. (image 5-52) 3.
  • Page 100 5. Random Access Image 5-52 Basic Width set up for Projector 1 Setting up the Width for Projector 2 ? 1. Press ENTER until Left is selected. (image 5-53) 2. Push the cursor key ← or → to adjust the left width until it matches the right width of projector 1. (image 5-54) 3.

  • Page 101: Reset

    5. Random Access 5.5.7.10 Reset Overview • Start up • Coarse Reset • Linearity Reset • Reset Fine • Reset Blanking/Soft Edge • Reset All What can be done with Reset ? With the Reset menu item, a selection, or all Geometry and Soft Edge adjustment values, can be reset to their default values. 5.5.7.10.1 Start up How to Start up Reset ? 1.

  • Page 102: Linearity Reset

    5. Random Access 5.5.7.10.3 Linearity Reset How to reset the Linearity adjustments ? 1. Push the cursor key ↑ or ↓ to highlight Linearity within the Geometry Reset menu. (menu 5-125) 2. Press ENTER to select. A warning will be displayed . (menu 5-126) 3.

  • Page 103: Reset All

    5. Random Access 4. Press ENTER to select the desired Blanking/Soft Edge Reset value. A warning will be displayed . (menu 5-131) 5. Press ENTER to reset the selected Blanking/Soft Edge adjustments Press EXIT to return to the Geometry Reset menu. GEOMETRY RESET SOFT EDGE RESET WARNING...

  • Page 104: Rename

    5. Random Access 5.5.8 Rename Start Up To change the name of a selected file: 1. Push the cursor key ↑ or ↓ to highlight Rename. (menu 5-134) 2. Press ENTER. The Rename selection menu will be displayed. (menu 5-135) 3.

  • Page 105: Copy

    5. Random Access 5.5.9 Copy Start Up To copy the name of a selected file : 1. Push the cursor key ↑ or ↓ to highlight Copy. (menu 5-137) 2. Press ENTER. The Copy selection menu will be displayed. (menu 5-138) 3.

  • Page 106: Geometry

    5. Random Access 4. Press ENTER to select. If [all] is selected, your password has to be entered before all files will be deleted. A confirmation menu "Delete file name ?" is displayed. (menu 5-142) 5. Press ENTER to delete the file, press EXIT if you want to keep it. Note: The active file cannot be deleted.

  • Page 107: Shift

    5. Random Access Size adjustment 1. Push the cursor key ↑ or ↓ to highlight Size. (menu 5-145) 2. Press ENTER to select. 3. Push the cursor key ↑ or ↓ to size the image in a vertical direction. Push the cursor key ← or → to size the image in a horizontal direction. GEOMETRY SIZE SHIFT...

  • Page 108: Blanking - Soft Edge

    5. Random Access How to adjust Keystone? 1. Push the cursor key ↑ or ↓ to highlight Keystone. (menu 5-147) 2. Press ENTER to select. 3. Push the cursor key ↑ or ↓ to adjust the keystone of the image. When the upper part of the image is wider than the lower part of the image, push the cursor key →.

  • Page 109: R5976420 Barcoreality Sim 6 Ultra

    6. INSTALLATION MODE Overview • Installation Mode Overview • Build-up • Start up • Input Slots • No signal • Barco logo • Lens Adjustment • Menu Position • 800 Peripheral • Configuration • OSD Color • Internal Patterns •...

  • Page 110: Installation Mode Overview

    6. Installation Mode 6.1 Installation Mode Overview Installation Mode Overview • Input Slots • No Signal Color [Blue/Black] Shutdown [On/Off] Shutdown Time • Barco Logo Status [On/Off] Background [On/Off] Shift Hot Key [Text/Off] • Lens Zoom/Focus Shift • Menu Position [Center/Edges] •...

  • Page 111: Start Up

    No signal: selection of a black or blue background color • Barco Logo: the Barco Logo can be added to the projected image, in overlay or on a background, on any place on the screen. • Lens: to perform lens adjustments •...

  • Page 112: No Signal

    6. Installation Mode The black indicated inputs are selectable and changeable. The gray indicated inputs are fix inputs and are not changeable. The indication in front of the digit means : x : valid signal connected to the input. - : no valid signal connected to the input. No module: the option is not installed How to change the Slot Selector ? 1.

  • Page 113: Changing The Background Color

    3. Push the cursor key ↑ or ↓ to highlight Color. 4. Press ENTER to toggle between [BLUE] or [BLACK]. INSTALLATION NO SIGNAL INPUT SLOTS COLOR [Blue] NO SIGNAL SHUTDOWN [off] BARCO LOGO LENS Shutdown time: 5 min MENU POSITION[CENTER] 800 PERIPHERAL MORE ... Select with ↑ or ↓...

  • Page 114: Barco Logo

    OFF: no key on the RCU is used to display the BARCO logo. TEXT: the TEXT key on the RCU is used to display or to remove the BARCO logo with one single push on this key (only in operational mode).

  • Page 115: Lens Adjustment

    Note: The zoom/focus function is only applied when a motorized zoom lens is mounted. 4. When finished, press EXIT to return to the installation menu or press ENTER to go to the shift function. INSTALLATION INPUT SLOTS NO SIGNAL BARCO LOGO LENS MENU POSITION[CENTER] 800 PERIPHERAL MORE ...

  • Page 116: Menu Position

    : - 5 mm to + 5 mm 4. When finished, press EXIT to return to the installation menu or press ENTER to go to the zoom/focus function. INSTALLATION INPUT SLOTS NO SIGNAL BARCO LOGO LENS MENU POSITION[CENTER] 800 PERIPHERAL MORE ...

  • Page 117: Defining The Output Module Of The Rcvds05

    800 PERIPHERAL INPUT SLOTS OUTPUT MODULE [STANDARD] OUTPUT MODULE [STANDARD] NO SIGNAL INFRARED [PPM] INFRARED [PPM] BARCO LOGO LENS MENU POSITION[CENTER] 800 PERIPHERAL MORE ... Select with ↑ or ↓ Select with ↑ or ↓ Select with ↑ or ↓...

  • Page 118: Configuration

    6. Installation Mode 6.10 Configuration What can be done ? The way of physical installation of the projector can be defined to the projector. The following installation configurations are possible: • front/table • front/ceiling • rear/table • rear/ceiling Choosing the right configuration 1.

  • Page 119: Shutter (Optional)

    6. Installation Mode Available patterns Outline Hatch Color bars Multiburst Checker board Page Char Alpha numeric char Character sets How to select an internal pattern ? 1. Push the cursor key ↑ or ↓ to highlight Internal Patterns. (menu 6-26) 2.
  • Page 120 6. Installation Mode Night Mode (Optional) Status The optional Night Mode improves the Black Level in e.g. night missions, the IG will generate nightly images and will control the dimmer on the projector. The night mode filter will be activated when the light output is dimmed to a certain level. the Night Mode Status will show the status of the night mode filter and the dimmer (Green = OK, Red = Error).

  • Page 121: Service Mode

    7. Service Mode 7. SERVICE MODE Overview • Service Mode Overview • Build-up • Start up • Identification • Change password • Change the address • Change Baudrate • Reset Lamp Runtime • Lamp Runtime history • I2C Diagnoses • Dimming •...

  • Page 122: Service Mode Overview

    7. Service Mode 7.1 Service Mode Overview Service Mode Overview • Identification Title Page Sim Options • Change Password • Change Proj. Address Projector Address Common Address (RC5) Common Address (PPM) • Change Baudrate PC • Reset Lamp Runtime • Lamp Runtime History •...

  • Page 123: Start Up

    7. Service Mode 7.3 Start up How to start up the service mode ? 1. Push the cursor key ↑ or ↓ to highlight Service. (menu 7-1) 2. Press ENTER to select. The Service Mode menu will be displayed. (menu 7-2) ADJUSTMENT MODE SERVICE SERVICE...

  • Page 124: Displaying The Identification Screen

    How to enable or disable the password function ? This item is password protected when the password strap is installed. The password function is enabled when the password strap on the controller module is installed. Consult an authorized Barco service technician to change the strap position.

  • Page 125: Change The Address

    7. Service Mode How to change the password ? 1. Push the cursor key ↑ or ↓ to highlight Change Password. (menu 7-9) 2. Press ENTER to display the Change Password menu. (menu 7-10) 4 ’_’ characters are displayed. A new password can be entered with the digit keys of the RCU or local keypad. Every time a digit is entered, a ’X’...

  • Page 126: Projector Address

    7. Service Mode 7.6.2 Projector Address How to change the Projector Address? 1. Push the cursor key ↑ or ↓ to highlight Projector Address. (menu 7-13) 2. Press ENTER to select. The actual address is filled in. The first digit is highlighted. CHANGE PROJ.

  • Page 127: Change Baudrate

    7. Service Mode 7.7 Change Baudrate Start up 1. Push the cursor key ↑ or ↓ to highlight Change Baudrate PC. (menu 7-15) 2. Press ENTER to display the Change Baudrate PC menu. (menu 7-16) The actual baudrate will be highlighted. The following baud rates are available: 230400/115200/57600/38400/19200/9600/4800/1200 3.

  • Page 128: I2C Diagnoses

    7. Service Mode Start up 1. Push the cursor key ↑ or ↓ to highlight Lamp Run Time History. (menu 7-19) 2. Press ENTER to display the Lamp Run Time overview. (menu 7-20) A listing with the lamp serial number and the corresponding run time will be displayed. The actual installed lamp will be marked.

  • Page 129: Dimming

    7. Service Mode 7.11 Dimming 7.11.1 Lamp Dimming How to perform lamp dimming ? 1. Push the cursor key ↑ or ↓ to highlight Dimming. (menu 7-23) 2. Press ENTER to select. The Dimming menu is displayed. Note: The Lamp Dimming function is not present in the SIM6 LL projector, the Dimming menu contains only the optional Mo- torized Dimming if present, otherwise the Dimming item in the service menu is grayed out See menu 7-24.

  • Page 130: Constant Light Output (Optional)

    7. Service Mode 7.11.3 Constant Light Output (Optional) The CLO menu item will be greyed out when this option is not installed. What can be done? In a multichannel setup, due to tolerances on the lamps and optical components (e.g. lenses), or due to the different positions of the projectors in relation to the screen, there will always be a difference in light output between the projectors.

  • Page 131: Uniformity

    7. Service Mode 7.12 Uniformity Changing these settings may seriously affect the performance of the projector. Start up 1. Push the cursor key ↑ or ↓ to highlight Uniformity. (menu 7-31) SERVICE UNIFORMITY ELECTRONIC CONVERGENCE DYNACOLOR GRAY LEVEL DEFINITION PURITY DISPLAY BLANKING PANEL ADJUSTMENT PRESET INPUT BALANCE...
  • Page 132 7. Service Mode 8. Use the BRIGHTNESS key to adjust the level of the selected color within the selection box e.g. raising the White Level. (im- age 7-4) 9. Press EXIT to return to the Service Mode menu. UNIFORMITY UNIFORMITY UNIFORMITY ADJUST GRAY <BRIGHTNESS>...
  • Page 133 7. Service Mode Image 7-4 Adjusting the level of the selected color within the selection box. How to set Uniformity back to the Default settings? 1. Push the cursor key ↑ or ↓ to highlight Default. (menu 7-35) 2. Press ENTER to set Uniformity back to the Default settings. UNIFORMITY ADJUST GRAY ADJUST BLACK...

  • Page 134: Electronic Convergence

    7. Service Mode How to Initialize the Black Uniformity settings? 1. Push the cursor key ↑ or ↓ to highlight Initialize Black. (menu 7-37) 2. Press ENTER to Initialize the Black Uniformity settings. UNIFORMITY ADJUST GRAY ADJUST BLACK ADJUST WHITE DEFAULT INITIALIZE WHITE INITIALIZE BLACK...

  • Page 135: Dynacolor

    7. Service Mode 7.14 DynaColor™ What is done? Due to the tolerance (lamps) and left-right setup (mirrors) of optical components, color differences may occur on the projected im- age(s). DynaColor™ allows a dynamic correction of these color differences, this is done by adding one primary color to another e.g. adding Green to Red, the adjustment is possible on the left side, right side or both sides.
  • Page 136 7. Service Mode COLOR BALANCE Primary Color to adjust Adjustment Side GREEN IN RED LEFT GREEN IN RED LEFT Image 7-6 Image 7-7 Select the desired Primary Color to adjust Select the left, right or both sides GREEN IN RED LEFT TINT Primary Color to add...

  • Page 137: Gray Level Definition

    7. Service Mode How to Initialize DynaColor? 1. Push the cursor key ↑ or ↓ to highlight Initialize. (menu 7-45) 2. Press ENTER to reset the DynaColor settings to 0. 3. Press EXIT to return to the Service Mode menu. DYNACOLOR ADJUST ACTIVE [OFF]...
  • Page 138 7. Service Mode 5. Push the cursor key ↑ or ↓ to select the desired Gray Level Range. The following Gray Level Ranges are available. Level Affected Gray Levels 0%-99% 12.5% 1%-24% 1%-49% 37.5% 26%-49% 1%-99% 62.5% 51%-74% 51%-99% 87.5% 76%-99% 100% 1%-100%...

  • Page 139: Purity

    7. Service Mode How to Initialize Gray level Definition? 1. Push the cursor key ↑ or ↓ to highlight Initialize. (menu 7-51) 2. Press ENTER reset the Gray level Definition settings to 0. 3. Press EXIT to return to the Service Mode menu. GRAY LEVEL DEFINITION ADJUST ACTIVE [OFF]...

  • Page 140: Display Blanking

    7. Service Mode Level +1 Level -1 Min. Level: 0 Max. Level: 255 Gray Levels Red Levels Green Levels Blue Levels Color Level Indication Image 7-11 Image 7-12 The Purity menu Purity color level indication 7.17 Display Blanking What can be done? Display Blanking is an additional blanking that can be used on an image which is already blanked through Geometry-Banking and/or Windowing-Blanking.
  • Page 141 7. Service Mode Image 7-15 Display Blanking Locations Each Display Blanking Location is described by 2 points, the Display Blanking Positions. Image 7-16 Display Blanking Positions The Display Blanking Location represents an edge, all information beyond this edge will be blanked out, the following image shows a Display Blanking adjustment for the Top Location.
  • Page 142 7. Service Mode Image 7-17 Display Blanking These Display Blanking Positions can be adjusted in steps of 1 pixel or steps of 1/32 pixel = subpixel. How to Start Up Display Blanking? 1. Push the cursor key ↑ or ↓ to highlight Display Blanking. (menu 7-53) 2.

  • Page 143: Panel Adjustments

    7. Service Mode How to Toggle Display Blanking On/Off? 1. Push the cursor key ↑ or ↓ to highlight Active [Off]. (menu 7-59) 2. Press ENTER to toggle Display Blanking On/Off. DISPLAY BLANKING ADJUST ACTIVE [ON] INITIALIZE Select with ↑ or ↓ <ENTER>...

  • Page 144: Preset Input Balance

    7. Service Mode 7.19 Preset Input Balance Changing these settings may seriously affect the performance of the projector. Start up 1. Push the cursor key ↑ or ↓ to highlight Preset Input Balance. (menu 7-63) 2. Press ENTER to select. The following warning will be displayed : (menu 7-64) Uniformity is reserved to qualified service personnel.

  • Page 145: Standard Source Setup Files

    A. Standard Source setup files A. STANDARD SOURCE SETUP FILES A.1 Table overview Table overview The following standard source files are pre-programmed in the projector. Name Resolution Fvert FHor Fpix Ptot Pact Ltot Lact sxga_50 1280x1024 50,000 19,102 87,948 1680 1280 1047 1024...
  • Page 146 A. Standard Source setup files Name Resolution Fvert FHor Fpix Ptot Pact Ltot Lact hd_25p 1920x1080 25,000 35,556 74,250 2640 1920 1125 1080 hd_30p 1920x1080 30,000 29,630 74,250 2200 1920 1125 1080 hd_60p 1280 60,000 22,222 74,250 1650 1280 x720 hd_25i 1920x562 25,000...

  • Page 147: Source Numbers 81 - 86 And 91 - 96

    B. Source Numbers 81 — 86 and 91 — 96 B. SOURCE NUMBERS 81 — 86 AND 91 — 96 B.1 Projector without any 800 peripheral connected Overview The source numbers 81 - 86 and 91 - 96 do not correspond to physical inputs. An additional adjustment file can be created for these source numbers.

  • Page 148: Source Numbers 81 - 86

    B. Source Numbers 81 — 86 and 91 — 96 source input 3 source input 3 file C source input 93 file C’ source input 6 source input 6 file F source input 96 file F’ Follow the same procedure as for a projector without a 800 peripheral connected. B.2.2 Source numbers 81 —...

  • Page 149: Cleaning The Dustfilter

    C. Cleaning the Dustfilter C. CLEANING THE DUSTFILTER C.1 Cleaning When should it be done? Depending on the environement, the dust filters should be cleaned at least when replacing the lamp. When the projector operates in dusty environement, clean the dust filters earlier than when replacing the lamp. How to clean the dustfilter? To clean the dustfilter, follow the next procedure : 1.
  • Page 150 C. Cleaning the Dustfilter R5976420 BARCOREALITY SIM 6 ULTRA 14052003...

  • Page 151: Index

    Index INDEX Numerics/Symbols Constant Light Output (Optional) % of image %% of image 5–Cable Input 800 Peripheral D15 Input Dimensions Projector Dimming Display Blanking Address 30–31 Dustfilter Program Cleaning DynaColor™ Projector Adjustment 26–27 Quick Set up 26–27 Lens Screen Color Edit File adjustments Start up...
  • Page 152 Geometry Reset 97–99 Horizontal Vertical Blanking Selection Coarse Start up Fine Logo Linearity Barco Logo Soft Edge Start up getting started Gray Level Definition Menu Position Motion Compensation Start up Motion Compensation (TMR) (Optional) I2C diagnoses Motorized Dimming (Optional) Identification 119–120...
