LCD Panel Open - Model D

3
5
3
2
1
4
5
6
7
8
10
9
Note that the Touchpad and
Buttons has a valid operational
area indicated within the dotted
lines above. See "Clickpad/
Touchpad Sensitivity (Models
A, C & D)" on page 2 - 12.
LCD Panel Open - Model D 1 - 11
Quick Start Guide
Figure 1 - 6
LCD Panel Open
Model D
1. Built-In 2.0M HD
PC Camera
2. PC Camera LED
3. Built-In Array
Microphone
4. LCD
5. Speakers
6. Power Button
7. LED Status
Indicators
8. Illuminated
Keyboard
9. Touchpad and
Buttons
10. Fingerprint Reader
Module
