EUROCOM X7 User Manual page 168

Upgrading The Computer
Figure 6 - 3
6
Battery Removal
(Model B & D
Computers)
6 - 6 Removing the Battery
For Model B & D Computers:
5. Slide the battery forward in the direction of the arrow on the battery
markers on the battery and case align
6. Lift the battery up out of the bay and remove it
7. When replacing the battery insert it on to the case until the case markers align
and then slide it until it locks.
3
4
6
.
4
.
5
5
4
until the
3
,
6
