Replacing the Hard Disk Drive Bay Cover

1. Reinsert the HDD bay cover by placing it on the bottom case assembly and then
slide it on to the case.
2. Make sure the case markers
3. Press down on the cover as illustrated
direction of arrow .
3
4. Replace the screw at point
1
line up before sliding any further.
1
, and then slide the cover in the
2
4
4
3
2
Upgrading The Computer
Upgrading the Hard Disk Drive(s) 6 - 15
Figure 6 - 11
HDD Bay Cover
Replacement
6
