LCD Panel Closed (Top View) - Model B/D

Model B computers feature a 5.0M Pixels / 1.0M HD dual camera system. Model D
computers feature a 5.0M Pixels / 2.0M HD dual camera system.
When the LCD is open, the camera facing you is the 1.0M HD camera (see
- 3 on page 1 - 8). The 5.0M Pixels camera (
which will be facing away from you when the LCD panel is open.
1
2
2
above) is located on the top case,
Figure 1
LCD Panel Closed (Top View) - Model B/D 1 - 9
Quick Start Guide
Figure 1 - 4
LCD Panel Closed
Model B/D
1. Top Case Logo
LED (Optional)
2. Built-In 1.0M HD
PC Camera

Top Case Logo LED
The top case logo LED
pictured here may differ
in appearance from the
design on your Model B/
D purchase option.
Note that the top case
logo LED is optional.
1
