Clickpad/Touchpad Sensitivity (Models A, C & D); Illuminated/Non-Illuminated Touchpad Sensitivity (Model B) - EUROCOM X7 User Manual

Storage Devices, Mouse & Audio
Clickpad/Touchpad Sensitivity (Models A, C & D)
2
The mouse button zones at the bottom of the pad measure about 15mm from the
bottom of the pad, and the left and right buttons are divided roughly down the mid-
dle as illustrated below. Press the left button zone for a left click, and right button
zone for a right click action.

Illuminated/Non-Illuminated Touchpad Sensitivity (Model B)

Note that the illuminated/non-illuminated Touchpad (Model B) has a defined valid
operational area of sensitivity indicated within the sensor area of the illustration be-
low:
• 4 mm from the top/bottom of the Touchpad edges, and 5 mm from the left/right
sides of the Touchpad.
Clickpad/Touchpad for Touchpad for
Model A, C & D Computers Model B Computers
Figure 2 - 9
Clickpad/Touchpad
Sensitivity
2 - 12 Clickpad/Touchpad and Buttons/Mouse
