Removing the Battery
If you are confident in undertaking upgrade procedures yourself, for safety reasons it is best to remove the battery.
1. Turn the computer off, remove the AC/DC adapter and turn it over.
2. Slide the latch
1
-
2
in the direction of the arrow.
3. Slide the battery forward in the direction of the arrow on the battery
align
.
4
4. Lift the battery
up
(Figure
3
a.
1
b.
3
4
b) and out of the battery bay.
2
until the markers on the battery and case
3
c.
5
Disassembly
Figure 1
Battery Removal
Slide the latch and
a.
hold it in place.
b. Slide the battery in the di-
rection of the arrow.
c. Lift the battery out of the
bay as indicated.
5. Battery
•
Removing the Battery 2 - 5
