Upgrading The Computer

Upgrading the System Memory (RAM)

The computer has four memory sockets for 204 pin Small Outline Dual In-line (SO-
DIMM) DDR III (DDR3) type memory modules (see "Memory" on page E - 2).
The total memory size is automatically detected by the POST routine once you turn
on your computer.
Two primary memory sockets are located under component bay cover (the bot-
tom case cover), and two secondary memory sockets are located under the key-
board (not user upgradable). If you are installing only two RAM modules then
6
they should be installed in the primary memory sockets under the component
bay cover.
Note that the RAM located under the keyboard is not user upgradable. Contact your
distributor/supplier for more information if you wish to upgrade the memory in the
secondary memory sockets.
6 - 16 Upgrading the System Memory (RAM)
