System Map: LCD Panel Open - Model A

2
4
5
6
7
8
9
1
The use of any portable electronic trans-
mission devices aboard aircraft is usually
prohibited. Make sure the module(s) are
OFF if you are using the computer aboard
aircraft.
Use the key combinations to toggle power
to the 3.75G/HSPA/WLAN/Bluetooth
modules, and check the LED indicator
3
icon to see if the modules are powered on
or not (see
Table 1 - 4, on page 1 -
Wireless Device
Operation Aboard Aircraft
Table 1 - 6, on page 1 -
9).
7
Touchpad Buttons
(valid operation area)
System Map: LCD Panel Open - Model A 1 - 7
Quick Start Guide
Figure 1 - 2
LCD Panel Open
(Model A Computers)
1. Built-In PC Camera
2. LCD
3. Power Button
4. Hot Key Buttons
5. Keyboard
6. Built-In Microphone
7. Touchpad &
Buttons
8. Fingerprint Module
(Optional)
13/
9. LED Indicators
