LCD Panel Open - Model A

2
5
3
1
4
5
6
7
8
9
Note that the Clickpad and
Buttons has a valid operation-
al area indicated within the
dotted lines above.
See "Click-
pad/Touchpad Sensitivity
(Models A, C & D)" on page 2
- 12.
10
LCD Panel Open - Model A 1 - 7
Quick Start Guide
Figure 1 - 2
LCD Panel Open
Model A
1. Built-In PC Camera
2. PC Camera LED
3. Built-In
Microphone
4. LCD
5. Speakers
6. LED Status
Indicators
7. Power Button
8. Illuminated
Keyboard
9. Clickpad and
Buttons
10. Fingerprint Reader
Module
