Quick Start Guide
1
Figure 1 - 3
LCD Panel Open
Model B
1. Built-In PC Camera
2. PC Camera LED
3. Built-In Microphone
4. LCD
5. Speakers
6. Power Button
7. LED Indicators
8. Illuminated Keyboard
9. Illuminated
TouchPad and
Buttons
10. Fingerprint Reader
(Optional)

1 - 8 LCD Panel Open - Model B

LCD Panel Open - Model B
5
2 3
1
4
5
7
8
9
10
Note that the Illuminated
Touchpad has a defined valid
operational area of sensitivity
indicated within the sensor
area of the illustration below.
See "Illuminated Touchpad
Sensitivity" on page 2 - 12.
6
