Upgrading The Computer
6
Figure 6 - 4
Memory Socket Cover
Removal

6 - 6 Upgrading the System Memory (RAM)

Upgrading the System Memory (RAM)
The computer has two memory sockets for 200 pin Small Outline Dual In-line
(SO-DIMM) - DDR 266 MHz - type memory modules. The main memory can
be expanded up to 1024MB. The SO-DIMMs supported are 256MB, and
512MB in size, and the total memory size is automatically detected by the
POST routine once you turn on your computer.

Memory Upgrade Process

1. Turn off the computer, and turn it over and remove the battery.
2. Remove screws -
1
.
cover
1 2
3 4
from the memory socket cover
4
, and remove the
5
5
