Upgrading the System Memory (RAM)

1. Turn off the computer, and turn it over and remove the battery.
2. Locate the RAM & CPU bay cover and remove screws
3. Carefully (a fan and cable are attached to the under side of the cover) lift up
the bay cover.
4. Carefully disconnect the fan cable
2
1
4
3
-
1
, and remove the cover
5
Fan Cable
Make sure you reconnect the fan cable
5 before screwing down the bay cover.
Upgrading the System Memory (RAM) 6 - 9
Upgrading The Computer
.
4
The computer has one
memory socket for 200
.
6
pin Small Outline Dual
In-line
DDRII
5
memory modules (see
"Memory" on page C -
2
ed module types).
6
The total memory size is
automatically detected
by the POST routine
once you turn on your
computer.
System Memory
(SO-DIMM)
(DDR2) type
for details of support-
Figure 6 - 8
Removing the RAM
& CPU Bay Cover
6
