SYSTEM12
INSTALLATION MANUAL
Programming
(continued)
VID4 (Video 4)
Description:
Switches S12's Panel 4 in Zone zz to a specific
Video ab.
Command:
&S12,VID4,zz,ab<cr>
Query:
&S12,VID4,zz?<cr>
Reply:
&S12,VID4,zz,ab<cr>
Parameters:
<cr>:
carriage return: Hexadecimal 0x0D or Decimal 13
zz:
Zone: 01-32
ab:
Input 01-16
00 = Track
Examples:
• &S12,VID4,03,02<cr> S12's Panel 4 in Zone 3
selects Input 2.
• &S12,VID4,29?<cr> Queries S12's Panel 4 in Zone
29 for selected video input.
• &S12,VID4,07,07<cr> S12's Panel 4 in Zone 7
selects Input 7.
• &S12,VID4,02,00<cr> Notifies S12 to place S12's
Panel 4 in Zone 2 in Tracking Mode.
VID5 (Video 5)
Description:
Switches S12's Monitor in Zone zz to a specific
Video ab.
Command:
&S12,VID5,zz,ab<cr>
Query:
&S12,VID5,zz?<cr>
Reply:
&S12,VID5,zz,ab<cr>
Parameters:
<cr>:
carriage return: Hexadecimal 0x0D or Decimal 13
zz:
Zone: 01-32
Page 72
E L A N
ab:
Input 01-16
00 = Track
Examples:
• &S12,VID5,03,02<cr> S12's Monitor in Zone 3
selects Input 2.
• &S12,VID5,29?<cr> Queries S12's Monitor in Zone
29 for selected video input.
• &S12,VID5,07,07<cr> S12's Monitor in Zone 7
selects Input 7.
• &S12,VID5,02,00<cr> Notifies S12 to place S12's
Monitor in Zone 2 in Tracking Mode.
VOR (Video Routing)
Description:
• Routes Unit u's Video Input ii to Output oo.
• Used in 16x16 mode.
• Works if S12 is off or on.
Command:
&S12,VOR,u,oo,ii<cr>
Query:
&S12,VOR,u,oo?<cr>
Reply:
&S12,VOR,u,oo,ii<cr>
Parameters:
<cr>:
carriage return: Hexadecimal 0x0D or Decimal 13
u:
Unit 1-4
oo:
Output 01-16
ii:
Input 01-16
Examples:
• &S12,VOR,1,13,01<cr> routes Unit 1 Input 1 to
Output 13.
• &S12,VOR,3,02?<cr> queries Unit 3's output 2.
• &S12,VOR,4,13,16<cr> routes Unit 4 Input 16 to
Output 13.
• &S12,VOR,2,13,12<cr> routes Unit 2 Input 12 to
Output 13.
