Elan System12 Installation Manual And User's Manual page 73

E L A N H O M E S Y S T E M S
Programming
(continued)
VID1 (Video 1)
Description:
Switches S12's Panel 1 in Zone zz to a specific
Video ab.
Command:
&S12,VID1,zz,ab<cr>
Query:
&S12,VID1,zz?<cr>
Reply:
&S12,VID1,zz,ab<cr>
Parameters:
<cr>:
carriage return: Hexadecimal 0x0D or Decimal 13
zz:
Zone: 01-32
ab:
Input 01-16
00 = Track
Examples:
• S12,VID1,03,02<cr> S12's Panel 1 in Zone 3
selects Input 2.
• &S12,VID1,29?<cr> Queries S12's Panel 1 in Zone
29 for selected video input.
• &S12,VID1,07,07<cr> S12's Panel 1 in Zone 7
selects Input 7.
• &S12,VID1,02,00<cr> Notifies S12 to place S12's
Panel 1 in Zone 2 in Tracking Mode.
VID2 (Video 2)
Description:
Switches S12's Panel 2 in Zone zz to a specific
Video ab.
Command:
&S12,VID2,zz,ab<cr>
Query:
&S12,VID2,zz?<cr>
Reply:
&S12,VID2,zz,ab<cr>
Parameters:
<cr>:
carriage return: Hexadecimal 0x0D or Decimal 13
zz:
Zone: 01-32
© ELAN Home Systems 2004 • All rights reserved.
SYSTEM12
ab:
Input 01-16
00 = Track
Examples:
• &S12,VID2,03,02<cr> S12's Panel 2 in Zone 3
selects Input 2.
• &S12,VID2,29?<cr> Queries S12's Panel 2 in Zone
29 for selected video input.
• &S12,VID2,07,07<cr> S12's Panel 2 in Zone 7
selects Input 7.
• &S12,VID2,02,00<cr> Notifies S12 to place S12's
Panel 2 in Zone 2 in Tracking Mode.
VID3 (Video 3)
Description:
Switches S12's Panel 3 in Zone zz to a specific
Video ab.
Command:
&S12,VID3,zz,ab<cr>
Query:
&S12,VID3,zz?<cr>
Reply:
&S12,VID3,zz,ab<cr>
Parameters:
<cr>:
carriage return: Hexadecimal 0x0D or Decimal 13
zz:
Zone: 01-32
ab:
Input 01-16
00 = Track
Examples:
• &S12,VID3,03,02<cr> S12's Panel 3 in Zone 3
selects Input 2.
• &S12,VID3,29?<cr> Queries S12's Panel 3 in Zone
29 for selected video input.
• &S12,VID3,07,07<cr> S12's Panel 3 in Zone 7
selects Input 7.
• &S12,VID3,02,00<cr> Notifies S12 to place S12's
Panel 3 in Zone 2 in Tracking Mode.
INSTALLATION MANUAL
Page 71
