gSC10
Rear Panel Connections
Dimension: 17"W x 2.25" H x 14" D (431.8mm W x 57.2mm H x 355.6mm D)
Serial
Serial
Sense Input
Connections
Connections
Connections
8 bi-directional
2 bi-directional
4 ELAN Sensor
RS-232 Ports
RS-485 Ports
input Ports
IR Outputs
10 discrete IR channels.
Compatible with Xantech
FEDERAL COMMUNICATIONS COMMISSION
INTERFERENCE STATEMENT:
single and dual emitters.
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15
of the FCC Rules.
These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference
by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
- Consult the dealer or an experienced radio/ TV technician for help.
9901335_ELAN_QuickGuide_gSC10_ENG_CHI_0314_PRINT.indd 3
Relay
Connections
10 Normally Open Relays
12VDC 24VAC @ 1 AMP
Compatibility
USB Modem Connections
USB - See Integration Notes
for compatible equipment
Ethernet Connection
Ethernet - 10/100 Mbps
PoE IEEE 802.3at Type 2
48 VDC, 600 mA
This radio transmitter has been approved by Industry Canada to operate with the antenna types listed below with the maximum permissible gain and required
antenna impedance for each antenna type indicated. Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type,
are strictly prohibited for use with this device.
Cet émetteur radio a été approuvé par Industrie Canada pour fonctionner avec les types d'antennes énumérés cidessous avec le gain maximal admissible et impédance
d'antenne requise pour chaque type d'antenne indiqué. Types d'antennes n'est pas inclus dans cette liste, ayant un gain supérieur au gain maximal indiqué pour ce type,
sont strictement interdits pour une utilisation avec cet appareil.
Antenna Type
Peak Gain
Dipole Antenna
2.09dBi
Informations concernant l'exposition aux fréquences radio (RF):
La puissance de sortie émise par l'appareil de sans fi l est inférieure à la limite 'exposition aux fréquences radio d'Industry Canada (IC). Utilisez l'appareil de sans fi l de
façon à minimiser les contacts humains lors du fonctionnement normal. Ce périphérique a également été évalué et démontré conforme aux limites d'exposition aux
RF d'IC dans des conditions d'exposition à des appareils mobiles (antennes sont supérieures à 20 cm à partir du corps d'une personne).
DC Power
Connection
Factory use
WIFI Antenna
English
ONLY
802.11 b/g/n
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
Reset
5. Do not use this apparatus near water.
Reset's the
6. Clean only with dry cloth.
7. Install in accordance with the manufacturer's instructions.
unit's IP address
8. Do not install near any heat sources such as radiators,
heat registers, stoves or other apparatus
to factory default
(including amplifi ers) that produce heat.
(DHCP).
9. Only use attachments/accessories specifi ed
by the manufacturer.
Press and hold
10. Unplug this apparatus during Iightning storms or when
for programming
unused for long periods of time.
11. Refer all servicing to qualifi ed service personnel.
reset.
Servicing is required when the apparatus has been
damaged in any way such as power-supply cord or plug
is damaged, liquid has been spilled or objects have
fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally,
or has been dropped.
FCC and IC Information:
This equipment complies with Part 15 of FCC RF Rules.
Operation is subject to the following two conditions:
1. This device may not cause interference and
2. This device must accept any interference, including
interference that may cause undesired operation
of the device.
© 2013 Core Brands, LLC. All rights reserved. ELAN
are registered trademarks of Core Brands, LLC, a Nortek company.
gSC10
Quick Install Guide
This Device complies with ICES-003 and RSS-210 of the IC Rules.
Operation is subject to the following two conditions:
1. This device may not cause interference and
2. This device must accept any interference received,
including interference that may cause undesired operation.
Warning: Changes or modifi cations to this unit not expressly
approved by the party responsible for compliance could void
the user's authority to operate the equipment.
FCC and IC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set
forth for an uncontrolled environment and meets the exemption
from the routine evaluation limits in section 2.5 of RSS 102.
1. This Transmitter must not be co-located or operating
in conjunction with any other antenna or transmitter.
2. This equipment complies with FCC RF radiation exposure
limits set forth for an uncontrolled environment.
This equipment should be installed and operated
with a minimum distance of 20 centimeters from user
and bystanders.
Warning: The device meets the exemption from the routine
evaluation limits in section 2.5 of RSS 102, and users can
obtain Canadian information on RF exposure and compliance
from the Canadian Representative Product Solutions Group
at Tel: (519) 763-4538.
Notice: Use only the antenna provided with the product:
R-SMA Antenna, Aristotle Enterprises Inc.
p/n RFA-02-L2M2-M10-N, gain of 2.0 dBi.
®
®
®
  , g!
and Panamax
P/N 9901335 Rev. D 03/2014
®
3/14/14 3:44 PM
