DVR User's Manual
Refer to the following table for brief description of functional items:
Item Description
1 Instant Recording
2 Audio On/Off
Select Camera
3
4 Display Mode
5 View Live Camera
6 Playback Video
7 Setup Menu
8 Search Event List
The functions on the remote monitoring software will be described in the
following sections.
5.3.1

To View Live Video

View live video from the cameras attached to the DVR by clicking <Live>
button on the main window toolbar.
Choose desired display mode – full-screen, 2x2 windows, 3x3 windows, and
4x4 windows – after the live images of the DVR are displayed on the main
window. When a dome camera is connected and viewed in single channel
full-screen mode, the dome camera control operation can be accessed. To
choose desired display mode and to operate dome camera control, refer to
the following sections.
5.3.1.1

Selecting Display Mode

Choose the number of windows to be displayed on the
main window. Click one of the display buttons in MODE
section. Available selections are 4, 9 and 16 camera
displays. To view certain window in full screen, either
double-click on the wanted window, or click on the
corresponding CAMERA button.
48
Item Description
9 Capture Snapshot
10 4:3 Viewing Aspect
11 HDD Status
12 Playback Control
13 Select Picture Size
14 Select Bandwidth Speed
15 Download DVRPlayer
