Installing Remote Monitoring Software - Optiview H.264 DVR System User Manual

5.2.2

Installing Remote Monitoring Software

Start the browser to initiate the installation of the remote monitoring software
on the PC. The IP address of the DVR can be saved as a Favorites item in
the web browser to enable easy access in the future.
Start the IE; it can be started either by clicking on the desktop icon, or by
using the Start menu to access it.
Enter the IP address of the DVR in the address bar at the top of the
browser.
The ActiveX controls and plug-ins dialog will show twice for confirmation;
click <Yes> to accept ActiveX plug-ins. The remote monitoring software
plug-ins will be downloaded and installed on the PC automatically when
the connection is successfully made.
in the address, for example, "192.068.080.006" should be entered
as "192.68.80.6". If the default trigger port 80 is changed into
another one, take port 81 for example, the IP address should be
entered as "192.68.80.6:81".
A version check starts to verify whether the remote monitoring software
was installed already, and also check if the version is the same as that
stored in that particular DVR. This process may take up to 30 seconds.
When the software is completely downloaded and installed, the Login
Screen is now displayed.
NOTE: Do not enter any leading "0" characters
DVR User's Manual
