DVR User's Manual
Viewing Live Image in Playback Mode
Press the MODE key repeatedly in playback mode, a 16-window viewing
mode contains both live and playback image appears. This viewing mode is
illustrated as the following figure.
The eight windows on the upper half of the screen playback the Live video
from channel 1 to channel 8 respectively, and the other windows allow users
to view Playback image from channel 1 to channel 8.
4.2

Sequence Setup

This section introduces the way to view sequence mode with both Main
Monitor and Call Monitor, if connected. Sequence function can avoid manual
backtracking and provides more flexibility while monitoring surveillance.
4.2.1

Sequence with Main Monitor

Automatic sequence function can be observed in any view mode. Select
certain view format and press SEQ to toggle the automatic sequence; press
ESC to stop sequencing. The figure below displays the 4-camera and
9-camera sequencing view modes.
30
