Playback Controls - Optiview H.264 DVR System User Manual

Follow below steps to play back a downloaded *.drv file with the remote
monitoring software.
Click <Open> and the file selection screen is displayed.
Select the *.drv video file to playback and click <OK>.
Click <OK> in the <Local Playback> Screen to start the playback, or click
<Cancel> to abort.
View the video playback using the Playback controls.
To end the playback, click <Live> to return to live video.
5.3.3.3

Playback Controls

When the local or remote video is being played, the remote monitoring
software is in Playback Mode. The playback controls toolbar will emerge on
the main window toolbar.The Playback controls and indicators are described
as below.
Icon Name
Fast Backawad /
⊲⊲
Step Backward
⊳ / ⌷⌷
Play / Pause
Fast Forward /
⊳⊳
Step Forward
Description
1. Click to play the recorded video in backward
direction. Click repeatedly to select the backward
playback speed: 1×, 2×, 4×, 8×, 16×, or 32×.
2. When playback is paused, click repeatedly to
move backward step-by-step.
1. While playing, click to pause the playback.
2. When paused, click to resume the playback.
1. Click to play the recorded video in forward
direction. Click repeatedly to select the forward
playback speed: 1×, 2×, 4×, 8×, 16×, or 32×.
2. When playback is paused, click repeatedly to
move forward step-by-step.
DVR User's Manual
Formatted: Indent: Left: 6 ch, Bulleted +
Level: 1 + Aligned at: 0" + Tab after:
0.29" + Indent at: 0.24"
Formatted: Left
53
