DVR User's Manual
4.5.1

Dome Connection

Follow the steps to install dome camera.
See Setup Guide for RS-485 port pin definition.
Connect the R+, R- terminals on the dome camera to the D+, D- terminals
on the RS-485 port by RS-485 cable respectively. Refer to the connection
figure illustrated in Setup Guide.
4.5.2

Dome Protocol Setup

The Dome Protocol item lists the available dome protocols for communicating
with dome cameras connected to the DVR. From the Main menu, select
<Camera Setup> and press ENTER. The following menu is displayed.
1. Analog Camera Select
2. Dome Protocol
3. Dome ID
4. Camera Title
5. Covert
6. Brightness
7. Contrast
8. Saturation
9. Hue
10. Audio Association
To configure dome protocol, select a camera first and set the communications
protocol associated with dome camera using the Direction keys and ENTER.
changes and exiting from the menu.
4.5.3

RS485 Setup

The DVR controls the domes via RS-485 communication protocol. The
RS-485 parameters in the DVR must be set to the same parameters set in
dome camera.
Users are allowed to change the RS-485 settings of the DVR. Select
<System Setup> in Main menu, then select <RS485 Setup> from the System
Setup menu and press ENTER. The following menu is displayed.
38
Analog Camera
NOTE: The settings become effective after saving the
RS485 Setup
CH1
None
0
No
0
0
0
0
Yes
