DVR User's Manual
4.2.2

Sequence with Call Monitor

Users are allowed to use the DVR front panel to control a call monitor display
without having to access the Main menu. Two viewing modes can be
displayed on call monitor: Sequence display and Single camera display. To
program the call monitor sequence, see OSD Menu Setup Guide, Section
Sequence Setup.
Follow the steps to control the call monitor.
Press the CALL key on the front panel to enter call monitor control mode.
The message "Call Mode" will be shown on the bottom-left of the screen.
Call Mode
Press CHANNEL key to display the associated camera on call monitor.
Alternatively, press SEQ repeatedly to display the sequence of cameras
previously programmed in Call Monitor Schedule menu.
Press ESC to return the front panel to Main monitor control mode.
4.3

Searching Recorded Video

The DVR is capable of searching and playing back recorded video by date
and time or events. Enter the specific date and time of the wanted video, the
DVR will search for matched video and start to playback the video.
Alternatively, users can search for event video by channel as well.
In live or playback mode, press SEARCH to enter the Search menu, which is
shown as follows.
----------------------------Search By Time----------------------------
From:
End:
Select:
----------------------------Search By Event----------------------------
Select Channel:
32
Press 1-16 Key To Select Channel
Press SEQ To Enable Sequence
Search
2008/01/01 00:00:00
2008/05/01 00:00:00
2008/01/01 00:00:00
CH1 CH2 CH3 CH4
Begin Playback
Event List
