5.3.5

Take a Snapshot

Snapshot is a simple screen capture tool. When users click on the
SNAPSHOT button, it will capture the screenshot of the window that is
currently showing on the screen. Each click captures one screenshot to be
saved as a JPEG file on the desktop. The snapshot file will be named as
"Snapshot-*".
5.3.6 Health Status of HDD
This function verifies the HDD status of the DVR. The following figure is an
example.
The information items shown in the chart are described as below:
Device Name
This item shows the model name of the HDD.
Int./Ext.
This item indicates whether the HDD is an internal or external device.
Total Size
This item indicates the total size of the HDD.
State
This item indicates whether the HDD is active or non-active.
Temperature
This item indicates the current temperature of the HDD in Celsius degree.
