Remote Monitoring Software; Remote Monitoring System Requirements - Optiview H.264 DVR System User Manual

DVR User's Manual
5.

Remote Monitoring Software

The remote monitoring software is a remote browser-based software
application designed to operate with the DVR products. Using the software,
users are allowed to view live and recorded video, and configure the DVRs
remotely via a LAN, WAN or Internet on a personal computer.
The connected PC will automatically download the remote monitoring
software plug-ins from the DVR when the DVR is connected by entering its IP
address in the address bar on the browser.
Due to the setting items are similar to those listed in the DVR's OSD setup
menu, please refer to the sections above for setting configuration of the
remote monitoring software.
The tasks can be performed with the remote monitoring software are listed
below:
Remote viewing of live/ recorded video
Remote setup of the DVR
Remote control of dome cameras
Alarm notification from the DVR
Up to three connections to one DVR using the remote monitoring software,
including one Administrator and two User operators
5.1

Remote Monitoring System Requirements

Items
Personal Computer
Hard Disk Drive
Operating System
Web Browser
Monitor Resolution
Video Card
Network Card
42
Requirements
Minimum:
Intel(R)® Pentium(R)® 4 CPU 3.20GHz (2 CPUs)
RAM 1 GB
Recommended:
Intel® Core™(TM)2 Quad CPU Q6600 @ 2.4GHZ
RAM 2 GB
20 MB available for software installation
Windows XP, Windows Vista
Microsoft Internet Explorer version 6.0 or above
Minimum 1024 x 768 with 16-bit color
NVIDIA GeForce 8400 GS 512MB
10Base-T (10 Mbps) or 100Base-TX (100 Mbps)
operation; must match the network configuration
