Monitor Resolutions - Intergraph RealiZm Graphics Z10 Hardware User's Manual

u
Dedicated 60-pin ribbon cable interface
u
Peak transfer rate of 132 MB per second
u
Up to two graphics board sets can be interfaced to a single Geometry Accelerator board

Monitor Resolutions

Z10, Z13, Z25, and V25 supports standard multi-sync monitors, including the Intergraph
17-inch and 21-inch monitors, at the following resolutions and maximum refresh rates (Hz).
Resolution
640 x 480
800 x 600
1024 x 768
1152 x 864
1280 x 960
1280 x 1024
1600 x 1200
1824 x 1368
Z13, Z25, and V25 support Intergraph InterVue-27 monitors at the following resolutions and
maximum refresh rates (Hz).
Resolution
640 x 480
800 x 600
1024 x 768
1280 x 960
1280 x 1024
1600 x 1200
1600 x 1280
Z10 Z13
85 85
85 85
85 85
76 85
85
85
Z13 Z25/V25
151 151
123 123
98 98
79 79
74 74
64
60
Z25/V25
85
85
85
85
85
85
75
65
59
