8. Install the new Z10 board or Z10-T board set in the slots from which you removed the
previously installed Z10 board or Z10-T board set.
If replacing a single Z10 board with a Z10-T board set, install the new Z10-T board set in
PCI slots 2 and 3.
If replacing two Z10 boards with Z10-T board sets in a deskside system, install one new
Z10-T board set in PCI slots 2 and 3, and the other in PCI slots 4 and 5.
9. If replacing Z10 in a dual-screen configuration, install the clock sync cable between the
Z10 boards or Z10-T board sets. Refer to the figures in step 4.
CAUTION The clock sync cable installs only one way. Do not force the keyed connector. Ensure pin 1
of both cable connectors engages pin 1 on both board connectors. The black wire connects
to pin 1.
10. Install the screws that were previously removed to secure the Z10 board or Z10-T board
set to the system chassis.
11. Close the system base unit.
12. Go to "Connecting the Video Cables" later in this chapter to connect the monitor and
VGA loopback cables.

Installing a Dual-Screen Upgrade

A dual-screen upgrade provides components to upgrade a TDZ workstation from a single-
screen configuration to a dual-screen configuration. Verify that you have the following items.
u
Z10 board or Z10-T board set
u
Diskette containing Intergraph video display driver software
u
Clock sync cable
u
Antistatic wrist strap
NOTE You cannot install a Z10-T dual-screen upgrade in a desktop system.
If an item is missing or damaged, notify the Intergraph Customer Response Center at
1-800-633-7248 immediately.
