Chapter 10: Monitoring Scans

Viewing Assessment Job Results

Introduction
Illustration
Description
Assessment
subtask explanation
144
You can open a scanning job in the Command Jobs window as the job runs to see
additional information it. Some information is not available until the job is complete.
The Remote Scan window presents a snapshot of the information available
Important:
when you open the job. To refresh the information, you must close and reopen the job.
Figure 35 is an example of the Remote Scan window showing a tree-view structure of an
assessment job and its tasks:
Figure 35: Remote Scan window showing the tree-view list of assessment tasks
The window contains a navigation pane, a left pane, and a right pane. (The example in
Figure 35 contains only the navigation and left panes.)
Assessment scans include a task for each group, and then for each asset criticality in each
group.The example in Figure 35 illustrates the subtasks for an ad hoc assessment scan.
Notice the components of the description:
This part of the description...
Finished Assessment X
on Scan_Group_Name for hosts with
Table 50: Subtask description
Describes...
for each group, a scan has at least one subtask
for each asset criticality represented in the
group, where is a consecutive number
X
assigned to those subtasks.
the name of the group for which the subtask
was run.
