2. PREPARATION

2.1 Assembling the Scanner

Assemble the stand before mounting the scanner unit. Eight bolts and an Allen wrench
are provided with the stand.
(1) Using four bolts, loosely attach the center bar (3) to side stay R (1) and side stay L
(2).
Attach the center bar loosely. Tighten the bolts securely after the scanner unit has
been mounted on the stand.
CS2000
( 1 ) ( 3 )
2. PREPARATION
( 2 )
2 – 1
