Selecting Channels

Selected channels are available for manual control through keypad commands, level wheel, and/or
ML controls. Element provides interactive ways to select channels including the control keypad and
groups. See "Selecting Groups" on page 123.
S e l e c t C h a n n e l s F r o m t h e K e y p a d
The keypad defaults to selecting channels. Channels may be selected on the control keypad using
the [+], [-], and [Thru] keys for consecutive or non-consecutive channel selection.
The following examples illustrate various methods of selecting channels from the control keypad:
• [5] [Enter] - selects channel 5.
• [5] [+] [7] [Enter] - selects non-consecutive channels 5 and 7.
• [5] [Thru] [9] [Enter]- selects channels 5 through 9.
• [2] [Thru] [8] [-] [5] [Enter] - selects a range of channels 2 through 8, except channel 5.
• [-] [6] [Enter] - removes channel 6 from the current selection list.
• [+] [1] [Enter] - adds channel 1 to the current list of channels.
N o t e :
[ N e x t ] a n d [ L a s t ]
The [Next] and [Last] buttons increment and decrement channel selection. If only one channel is
selected, [Next] increments the channel selection to the next sequential channel, while [Last]
decrements the channel selection by one.
Select channel 10 then change the selection to channel 11 using the [Next] key:
•
Channel 10 is selected with a gold outline around the entire channel and the channel
number is indicated in white.
•
Channel 11 is now selected with a gold outline and white channel number while channel 10
is no longer selected.
When a group of channels is selected, pressing [Next] or [Last] selects the first or last channel in
the channel list.
For Example:
Channels 11 through 20 are selected:
•
Channels 11 through 20 are still the specified channel list but only channel 11 is selected
for control. You can now sequentially press [Next] or [Last] to cycle through the list.
N o t e :
7
Basic Manual Control
You may use [+] and [-] multiple times to add or remove multiple channels from
the selection. [Thru] lists may be entered in ascending or descending order.
[1] [0] [Enter]
[Next]
[Next]
[Thru], [Next] and [Last] are affected by the current Flexichannel (use of the
[Flexi] key) state. See "Using Flexichannel" on page 23.
