Recording and Editing Cues from Blind

Press [Blind] and the selected cue will be displayed. You can make changes to cues in the blind
display using either the summary, table, or spreadsheet views. Use the [Format] key to toggle
between the three views.
C A U T I O N :
N o t e :
If changes are made in the blind display to an active cue, these changes will not impact the current
stage state.
Move instructions can be removed from a cue by selecting the channel and pressing [At] [Enter].
This allows all values from the previous cue to track into the current cue. You can also use this
command for specific parameters as well.
For Example:
Suppose you are in blind cue 5 and you make changes to channels 1-5:
•
Intensity goes to 50% and Iris to 35%. You decide to remove the Iris instruction:
•
The Iris value from the previous cue tracks in. Then you remove the intensity change as
well:
•
All values from the previous cue track in.
Instead of using multiple commands, you can, in one command, return the channels to their
values from the previous cue:
•
The impact of blind edits on subsequent cues is determined by the default setting of Track/Cue Only
mode. Obviously in tracking mode any changes will track forward until the next move instruction,
unless [Cue Only] is pressed. In cue only mode any changes will apply only to the selected cue. If
you want values to track forward, the [Track] button will allow it. The track/cue only instruction must
be applied when a value is entered. {Trace} can also be used to have changes trace back to the
initial move instruction. Such as:
•
-or-
•
116
Edits in blind take effect immediately. [Record] or [Update] commands are not
required in blind.
If preserve last cue has been enabled in Setup> Desk> Manual Control>
Preserve Blind Cue, the last cue you were looking at in blind will be displayed.
To force blind to the selected cue, press [Shift] & [Blind].
[1] [Thru] [5] [At] [5] <0> {Iris} [3] [5] [Enter]
{Iris} [At] [Enter]
{Intensity} [At] [Enter]
[1] [Thru] [5] [At] [Enter]
[1] [Thru] [5] [At] [5] <0> [Cue Only/Track] [Enter]
[1] [Thru] [5] [At] [5] <0> [Cue Only/Track] {Trace} [Enter]
Element User Manual
