Opening Setup

There are two ways to open the setup screen. You can either press [Setup] or press [Browser] and
scroll down to {Setup}.
The CIA will display the setup screen and the softkeys will change. Element will default to
displaying show settings, however if you change the view, Element will remember the view you
were in when you return to setup.
The setup displays are:

• Show

• Desk
N o t e :
S h o w
When you select the {Show} softkey, the CIA will display the following buttons:
• Show Settings
• Cue Settings
• Show Control
S h o w S e t t i n g s
Click {Show Settings} to enter this category.
Seven fields will be available to you: {Num of Channels}, {Dim. Dbl. Offset}, {Allow HS Fades},
{Fader Mode}, {Mark Time}, {Startup Macro}, and {Disconnect Macro}.
{Num of Channels}
You may use this field to set the number of channels in your Element up to 10,000. However, you
are limited to only patch up to the number of channels that are available from your system, either
250 or 500 depending on the channel count for your Element. Enter the number of channels for
your system using the keypad. This is useful for controlling paging. This entry must be confirmed
with the [Enter] key.
{Dim. Dbl. Offset}
This allows you to set the address offset for dimmer doubling. The default for this is 20000, to match
the Net2 standard offset, including Sensor dimming software. For dimmer doubling over Local
DMX, this value should be set to 256.
{Allow HS Fades}
Hue and saturation (HS) color data normally fades in native space. Enabling {Allow HS Fades} will
make HS data fade in HS space.
{Fader Mode}
This field allows you to set the fader mode for the cue list. Options toggle between Proportional
Master, Intensity Master, and Manual Master. For more information on Proportional and Intensity
Masters, See "Proportional vs. Intensity Master" on page
See "Manual Master Option" on page 134.
38
To select buttons in the show and desk displays, you can either use a mouse or
the arrow keys on Element along with the {Properties} softkey. {Properties} will
allow you to scroll through the fields and pressing [Select] will choose a field.
Pressing [Select] again will toggle options, such as 'Enabled' and 'Disabled".
Some fields require data from the keypad and then [Enter]. Selecting
{Properties} again will return the scroll ability to the buttons on the left of the CIA.
93.For information on Manual Master,
