S u m m a r y V i e w
The summary view displays the largest number of channels of any of the formats. Below you can
see channels 1-80 are shown. This format is best used to see large numbers of channels' intensity
data or parameter category data. Individual non-intensity parameters are not visible in this view.
Intensity data
Channel numbers
Unpatched channel F, C, B data Deleted channel
Z o o m i ng D i s p l a y s
You may zoom the table and summary view to display more or less channels. To do this, press and
hold the [Format] button and scroll the Level Wheel to alter the number of channels visible.
Scrolling the wheel up zooms in. Scrolling the wheel down zooms out. Zooming this display when
it is in 100 channel mode is not supported. A mouse can also be used to control zooming by holding
down the left button while using the scroll wheel.
