Determining Which Devices Use Dial Plan Tables - 3Com SuperStack 3 NBX Administrator's Manual

Determining Which
Devices Use
Dial Plan Tables
You can view or change the devices associated with a particular dial plan:
1 In the NBX NetSet – Main Menu window, click Dial Plan. The Dial Plan
window appears, displaying the Operations tab (Figure 3).
2 Click the Tables tab (Figure 14).
Figure 14 Tables Tab
3 From the list, select a dial plan table for which you want to list associated
devices. To list devices not assigned to any table, select (none).
4 Click Devices Using. The Devices Using Dial Plan dialog box appears
(Figure 15). For a description of the field definitions, see Table 12 at the
end of this section. If you select (none), the Devices That Have No Dial
Plan dialog box appears.
Managing Dial Plan Tables 69
