Toll Calls Without A Vtl Password; Music On Hold - 3Com SuperStack 3 NBX Administrator's Manual

Toll Calls Without a
VTL Password

Music On Hold

For the second two DestinationRoutes, two DestinationRouteOperation
Create commands perform two similar functions.
The stripLead command removes the two digits (72 or 73) leaving the
■
4-digit extension the user dialed.
The prepend command adds the IP Address of the destination NBX
■
system and the password of that system to the extension that the user
dialed. In this example, the IP address for Atlanta is 192.169.25.100
and the password is ATLPassW. For Dallas, the IP address is
192.168.35.100 and the password is DALPWord. In the dial plan, you
must use an asterisk (*) instead of a period (.) to separate the fields
within the IP address, and to separate the IP address from the
destination extension.
To place a hop-off call to 555-1212 in area code 903 through the Atlanta
system, a user on a remote system would dial 72919035551212. The 72
code sets up a VTL connection to Atlanta that incudes the Atlanta
system's VTL password, and the remaining digits are used to dial the
number (9 accesses an outside line to obtain dial tone from the local
carrier, 1 accesses the long-distance carrier, and the remaining digits
specify the long-distance number).
If the same user used site code 62 to place a call to the Atlanta office,
only toll-free, emergency, and internal call would be allowed.
If a local user has configured his telephone to forward calls to a
long-distance number, then an incoming VTL call to that telephone does
not need to supply the local system's VTL password in order for the call to
be forwarded.
If two users are talking on a VTL connection, and the first user places the
call on hold, the second user hears Music On Hold only if his local system
is configured to play it.
Using a VTL Password 113
