Modifying a Dial Plan
Configuration File
Figure 7 Dial Plan Report — Partial Dialog Box
Errors can prevent calls from being successfully routed. Warnings are
conditions that you can easily correct to successfully route the call.
4 When you are finished, click Close at the bottom of the screen.
This section describes how to modify the currently loaded dial plan
configuration file.
CAUTION: Modifications must be syntactically correct. Each time that the
system imports a dial plan configuration file, it verifies the file for errors
and displays the results. To avoid typing mistakes, 3Com suggests that
you start with an existing dial plan (for example, one of the default plans
that are shipped with the NBX system or a plan from another NBX
system), modify it, and save it as a renamed file.
To modify a dial plan configuration file:
1 In the NBX NetSet – Main Menu window, click Dial Plan. The Dial Plan
window appears, displaying the Operations tab (Figure 3).
2 Click Modify . The Modify Dial Plan dialog box shows a partial display
(Figure 8). Scroll up and down the browser window to see the complete
dial plan.
Managing the Dial Plan Configuration File 53
