3Com SUPERSTACK 3 Quick Reference Manual

3Com SUPERSTACK 3 Quick Reference Manual

4400 series
Hide thumbs Also See for SUPERSTACK 3:

Advertisement

Quick Links

Download this manual
S
M

Summary of Software Features

summarizes the software features that are supported by the Switch 4400 Series
This table
Management Software Version 4.0x
Feature
Automatic IP Configuration
Resilient Links
Aggregated Links
Broadcast Storm Control
Virtual LANs (VLANs)
Link Aggregation Control Protocol (LACP)
Multicast Filtering
Spanning Tree Protocol
Rapid Spanning Tree Protocol
Roving Analysis Port
Webcache Support*
Basic Traffic Prioritization
Advanced Traffic Prioritization*
RMON
Email, SMS and Pager Notification of Events
Management
RADIUS Authentication of Switch Management
Login*
Port Security
Configuration Save and Restore
Power over Ethernet †
* To make this operation available on the SuperStack 3 Switch 4400 SE, upgrade the product using the Switch 4400 SE
Enhanced Software Upgrade (3C17207).
† This feature is only available on the Switch 4400 PWR (3C17205).
For further information on how each of these features operates on your Switch please refer to the
Implementation Guide which is supplied on the CD-ROM that accompanies your Switch.
®
S
UPER
TACK
ANAGEMENT
.
3 S
4400 S
WITCH
Q
R
UICK
EFERENCE
Switch 4400
Supported using DHCP, BootP and Auto IP
Supported
Supported stack-wide
Supported
Support for up to 64 VLANs using the IEEE Std 802.1Q-1998
Supported using the IEEE Std 802.3-2002 (incorporating 802.3ad)
128 Multicast filter groups supported
■
IGMP filtering supported
■
Supported using the IEEE Std 802.1D, 1998 Edition
Supported using the IEEE Std 802.1w-2001
Supported
Supported
Supported
Supported
Four groups supported: Statistics, History, Alarms, Event
Supported
Web interface, command line interface, and SNMP supported
Supported
Disconnect Unauthorized Device (DUD) and Network Login*
(using the IEEE Std 802.1X-2001) supported
Supported
Supported (802.3af power over signal pairs)
1
ERIES
G
UIDE

Advertisement

loading
Need help?

Need help?

Do you have a question about the SUPERSTACK 3 and is the answer not in the manual?

Questions and answers

Related Manuals for 3Com SUPERSTACK 3

Summary of Contents for 3Com SUPERSTACK 3

  • Page 1: Summary Of Software Features

    Power over Ethernet † Supported (802.3af power over signal pairs) * To make this operation available on the SuperStack 3 Switch 4400 SE, upgrade the product using the Switch 4400 SE Enhanced Software Upgrade (3C17207). † This feature is only available on the Switch 4400 PWR (3C17205).
  • Page 2 Retries* Modify* Shared Secret* Summary* * To make this operation available on the SuperStack 3 Switch 4400 SE, upgrade Authentication Folder * the product using the Switch 4400 SE Enhanced Software Upgrade (3C17207). Display* † This operation is only available on the Switch 4400 PWR (3C17205).
  • Page 3 Web Interface Device Mimic Name Notepad History-1 Hour Setup History-48 Hours Statistics Port Setup Summary Port Security Setup Setup Unit For example purposes only, this graphic shows a Switch 4400 PWR. A Quick Guide to the Web Interface Operations This table describes the operations that are available in the Web Interface. Operation What does the Operation do? System Getting Started...
  • Page 4 Operation (Continued) What does the Operation do? System Telnet Connect Starts a Telnet session to the stack in a separate window. System Unit Name Assigns a name to the unit. System Unit Notepad Opens a notepad for the unit. System Backup Configuration Save Saves the current configuration of the stack to a file.
  • Page 5 Security RADIUS Summary* Displays summary information on RADIUS. * To make this operation available on the SuperStack 3 Switch 4400 SE, upgrade the product using the Switch 4400 SE Enhanced Software Upgrade (3C17207). † This operation is only available on the Switch 4400 PWR (3C17205).
  • Page 6 * To make this operation available on the SuperStack 3 Switch 4400 SE, upgrade the product using the Switch 4400 SE Enhanced Software Upgrade (3C17207). † This operation is only available on the Switch 4400 PWR (3C17205)
  • Page 7 * To make this operation available on the SuperStack 3 Switch 4400 SE, upgrade the product using the Switch 4400 SE Enhanced Software Upgrade (3C17207). ** This operation is only available on the SuperStack 3 4400 SE.
  • Page 8 * To make this operation available on the SuperStack 3 Switch 4400 SE, upgrade the product using the Switch 4400 SE Enhanced Software Upgrade (3C17207). ** This operation is only available on the SuperStack 3 4400 SE.
  • Page 9 A Quick Guide to the Command Line Interface Commands This table describes the commands that are available in the Command Line Interface. Command What does the Command do? bridge addressDatabase add Adds a statically configured address. bridge addressDatabase agingTime Sets the bridge address aging time. bridge addressDatabase find Finds an address.
  • Page 10 † Displays Power over Ethernet details for one port. physicalInterface power profile summary † Displays power requirements for 3Com Power over Ethernet products. physicalInterface power state † Enables or disables Power over Ethernet on a port by port basis.
  • Page 11 Command (Continued) What does the Command do? protocol ip initializeConfig Resets IP information to factory defaults. protocol ip interface modify Modifies IP interface information. protocol ip interface summary Displays summary information on the IP interface. protocol ip ping Polls remote devices. protocol ip route default Defines the default route in the routing table.
  • Page 12 Command (Continued) What does the Command do? security radius accounting modify* Modifies RADIUS accounting configuration. security radius authentication display* Displays RADIUS authentication statistics. security radius authentication modify* Modifies RADIUS authentication configuration. security radius retries* Modifies RADIUS retry parameters. security radius setup* Performs RADIUS configuration.
  • Page 13 Displays summary information on a traffic shaper. * To make this operation available on the SuperStack 3 Switch 4400 SE, upgrade the product using the Switch 4400 SE Enhanced Software Upgrade (3C17207). ** This operation is only available on the SuperStack 3 Switch 4400 SE.
  • Page 16 Copyright © 2004, 3Com Corporation. All rights reserved. Unless otherwise indicated, 3Com registered trademarks are registered in the United States and may or may not be registered in other countries. 3Com, the 3Com logo and SuperStack are registered trademarks of 3Com Corporation.
