Modifying an To modify an extension list:
Extension List
1 On the Extension Lists tab (Figure 11), select an extension list.
2 Click Modify. The Modify Extension List dialog box appears (Figure 13).
Figure 13 Modify Extension List Dialog Box
3 To modify the name of the Extension List, edit the contents of the Name
text box.
If you change the name of an extension list, you invalidate any aspect
of the dial plan that refers to the name. You must change all references
to the extension list name in the dial plan configuration file. If you made
your changes using an editor (as opposed to modifying the dial plan from
within the NBX NetSet utility), you must reimport the dial plan.
4 If you want calls to cycle through the extensions in the list, check the
Cycle Extensions checkbox. Each time that the system accesses the
extension list, it uses the next extension in the list. This arrangement
effectively progresses through the list to balance the load of calls. If Cycle
Extensions is not checked, the extension selection always starts from the
top of the list.
5 To add an extension to the Extensions in List scroll list, select it in the
Extensions not in List scroll list and click the << button. Use Shift+click to
select a block of extensions, or Ctrl+click to select several extensions at
different locations in the list.
Managing Extension Lists 67
