Table Create 1 Internal 4 Digit Extensions
/
/
TableEntry Create
TableEntry Create
/
/
DestinationRoute Create
DestinationRoute Create
/
/
DestinationRouteEntry Create
DestinationRouteEntry Create
/
/
DestinationRouteOperation Create
DestinationRouteOperation Create
DestinationRouteOperation Create
DestinationRouteOperation Create
Figure 31 Sample Dial Plan Entries for Chicago Using Site Codes
Id Entry Digits
-- ----- ----------- --- --- -------------
1 100 62
1 101 63
Route Description
----- -----------
522 Atlanta VTL Connection
523 Dallas VTL Connection
Route Entry DestinationExtension
----- ----- --------------------
522
523
Route Entry OperId Operation
----- ----- ------ ---------
522
522
523
523
The first TableEntry Create command creates entry 100 in Table 1. This
assumes that the highest previous entry in Table 1 was 99 or lower. Entry
100 watches for the 2-digit sequence 62 followed by a 4-digit extension
and specifies route 522 whenever a user dials such a 6-digit (Min = 6 and
Max = 6) sequence. Entry 101 watches for the 2-digit sequence 63
followed by a 4-digit extension and specifies route 523 whenever a user
dials such a 6-digit sequence. The choice of route numbers is made by the
person configuring the dial plans for the sites.
Two DestinationRoute Create commands create routes 522 and 523. The
Description field contains any text you want to use to describe each
route.
Two DestinationRouteEntry Create commands specify the extension list
for routes 522 and 523. Extension list *0006 is the default extension list
for VTLs.
How to Configure a Virtual Tie Line
Min Max Class
6 6 WAN
6 6 WAN
1 *0006
1 *0006
1 1 stripLead
1 2 prepend
1 1 stripLead
1 2 prepend
95
Prio Route
---- -----
0 522
0 523
Value
-----
2
192*168*25*100*
2
192*168*35*100*
