Creating a Delayed
Ringing Pattern
specify the extension of the telephone that you want as the Busy
Lamp/Speed Dial target.
You can define a ringing progression for a line that is mapped to multiple
telephones. For example, you can configure a call to ring immediately at
telephone 1, begin ringing at telephone 2 after 4 rings, and then begin
ringing at telephone 3 after 8 rings. Any of the telephones can pick up
the call at any time, even if it has not yet started audibly ringing at a
particular telephone. (The light is flashing during all rings.)
Delayed ringing works with Key mode only, that is, with line card ports
mapped to buttons on two or more telephones.
Delayed ringing is useful for backup coverage on shared lines, such as for
secretaries who must cover each other's lines.
Additional considerations:
The first telephone and each succeeding telephone in a delayed
■
ringing pattern continue to ring until the call is answered or
transferred to the Auto Attendant.
Telephones belonging to a delayed ringing pattern do not need to
■
belong to the same group. As long as all the telephones have the
same line mapped, you can create the delayed ringing pattern.
To create a delayed ringing pattern:
1 Use the Group Button Mappings feature of the NBX NetSet utility to map a
CO line.
2 Set Ring to Yes .
3 Clear the Lock check box. See Changing Device IP Settings
4 In the NBX NetSet - Main Menu window, click Device Configuration .
5 On the Telephones tab, choose the second telephone in the progression
of telephones where you want to create the Delayed Ringing pattern, and
then click the Button Mappings button.
6 For the shared line appearance button, set the Ring box to the behavior
that you want.
To have the telephone begin ringing after one ring, select
rings, select . Select
2
functions to indicate ringing/call status.) Do not change the settings in
the Type , Number , and Prty boxes.
Creating and Managing Button Mappings
to disable ringing entirely. (The indicator light still
No
171
after two
1;
