Importing And Exporting Dial Plan Configuration Files - 3Com SuperStack 3 NBX Administrator's Manual

Importing and
Exporting Dial Plan
Configuration Files
You create new entries in the dial plan configuration file by typing in new
commands (see "Dial Plan Configuration File Commands" later in this
chapter) or by cutting, pasting and editing existing lines in the file.
When you cut and paste new lines into dial plan tables, be sure to change
the Entry number in the pasted line. If two or more lines have the same
Entry number, the NBX system replaces the first one with the second;
therefore, only the last one takes effect.
You import a dial plan configuration file either to implement changes you
have made by editing the file, or to reload a previously saved
configuration.
From the Operations tab of the Dial Plan window, you can:
Import a North American Dial Plan
■
Import an International Dial Plan
■
This section concludes with a discussion of:
International Dial Plan Issues
■
When you export the working dial plan, the NBX system constructs a new
configuration file from the values in the database and displays it. The new
file shows the current date and time. You name the file when you save it.
The sample default files include examples of such things as timed routes
and pretranslators. To preserve the default (sample) dial plan
configuration included with the system, 3Com advises you to choose a
unique file name different than any of the default (sample) dial plan
configuration files so that you do not overwrite the sample default files.
Import a North American Dial Plan
The default dial plan for the SuperStack 3 NBX system is
NorthAmerica-4-digit.txt
system is
NorthAmerica.txt.
for use in other countries.
Always read the system Release Notes (called
up-to-date information on dial plans.
Managing the Dial Plan Configuration File
. The default dial plan for the NBX 100
Some customized dial plans are provided
readme.txt
45
) for the most
