Roll X Is Selected. (X Is 1 (Upper) Or 2 (Lower)); Roll X Is Empty. (X Is 1 (Upper) Or 2 (Lower)) - Canon imagePROGRAF iPF825 MFP M40 User Manual

Roll x is selected. (x is 1 (Upper) or 2 (Lower))

The indicated roll is specified for a print job sent from a
computer, but that roll is not loaded.

Roll x is empty. (x is 1 (Upper) or 2 (Lower))

"Lift the release lever and replace the roll."
The roll is empty.
There is remaining roll paper, but because it could not be
advanced, it could not be detected.
iPF825
Cause
Cause
Error Message
Corrective Action
Load the indicated roll and try printing again.
To print on a sheet instead, hold down the Stop button for
more than a second to cancel printing, load a sheet, and then
print.
(See "Loading and Printing on Sheets.")
Corrective Action
Follow these steps to replace the used roll with a new roll
of the same type and size.
1. Lift the Release Lever and remove the roll.
(See "Removing the Roll from the Printer.")
→P.644
(See "Removing the Roll Holder from Rolls.")
→P.649
2. Load the new roll.
(See "Attaching the Roll Holder to Rolls.")
(See "Loading Rolls in the Printer.")
3. If no barcode was printed on the roll, specify the type
of paper.
(See "Selecting the Paper Type (Roll).")
4. If no barcode was printed on the roll, specify the paper
length.
(See "Specifying the Paper Length (Roll).")
→P.643
5. If "Not finished printing. Finish printing remaining
jobs?" is shown on the Display Screen, press the OK
button.
Printing will resume, starting from the page on which
the error occurred.
Choose a higher level of Print Quality in the Advanced
Settings of the printer driver and try printing again.
(See "Giving Priority to Particular Graphic Elements
and Colors for Printing.")
Roll x is selected. (x is 1 (Upper) or 2 (Lower))
> Messages regarding paper
→P.8
→P.629
→P.634
→P.642
→P.56
>
