iPF840 Series
Cause
A print job for rolls was received when a
sheet is loaded.

Roll x is selected. (x is 1 (Upper) or 2 (Lower))

Roll x is selected. (x is 1 (Upper) or 2 (Lower))
Cause
The indicated roll is specified for a print job sent
from a computer, but that roll is not loaded.

Roll x is empty. (x is 1 (Upper) or 2 (Lower))

Roll x is empty. (x is 1 (Upper) or 2 (Lower))
Cause
The tailing edge of
the paper was detec-
1.
ted because cut
sheets were loaded in
2.
the roll paper Paper
Feed Slot.
3.
4.
5.

"Lift the release lever and replace the roll."

The roll is empty.
There is remaining roll paper, but because it could not be ad-
vanced, it could not be detected.
Basic Guide
(See "Loading Rolls in the Printer.")
The printer now starts printing the print job.
Press ▲ or ▼ to select Stop Printing, and then press the OK button.
Follow these steps to install the roll paper.
Press the OK button and remove the paper.
Load the new roll.
(See "Attaching the Roll Holder to Rolls.")
(See "Loading Rolls in the Printer.")
If no barcode was printed on the roll, specify the type of paper.
(See "Changing the Type of Paper.")
If no barcode was printed on the roll, specify the paper length.
(See "Specifying the Paper Length.")
If "Not finished printing. Finish printing remaining jobs?" is shown on the Display Screen, press the
OK button.
Printing will resume, starting from the page on which the error occurred.
Cause
Corrective Action
➔
Press ▲ or ▼ to select "Load Roll Paper", and then press the OK button.
Load the roll, and then print.
(See "Attaching the Roll Holder to Rolls.")
(See "Loading Rolls in the Printer.")
Press ▲ or ▼ and select Stop Printing or press the Stop button to stop
printing.
Corrective Action
P.12
➔
P.15
➔
User's Guide
➔
User's Guide
➔
Follow these steps to replace the used roll with a new roll of the
same type and size.
1.
Lift the Release Lever and remove the roll.
(See "Removing the Roll from the Printer.")
(See "Removing the Roll Holder from Rolls.")
2.
Load the new roll.
(See "Attaching the Roll Holder to Rolls.")
(See "Loading Rolls in the Printer.")
3.
If no barcode was printed on the roll, specify the type of paper.
(See "Changing the Type of Paper.")
4.
If no barcode was printed on the roll, specify the paper length.
(See "Specifying the Paper Length.")
5.
If "Not finished printing. Finish printing remaining jobs?" is
shown on the Display Screen, press the OK button.
Printing will resume, starting from the page on which the error
occurred.
The unused portion of the roll is heavy, and this is placing a bur-
den on the printer. It may be helpful to change the printing mode,
which will change the paper feed timing.
Roll x is selected. (x is 1 (Upper) or 2 (Lower))
P.15
Corrective Action
P.12
➔
P.15
➔
Corrective Action
➔
P.12
➔
P.15
➔
User's Guide
➔
User's Guide
➔
P.21
User's Guide
➔
