Printer parts
Front ................................................................................................................................................................ 693
Back ................................................................................................................................................................ 695
Top Cover (Inside) ........................................................................................................................................... 696
Carriage ........................................................................................................................................................... 697
Ink Tank Cover (Inside) ................................................................................................................................... 698
Front
a. Top Cover
Open this cover to install the Printhead, load paper, and remove any jammed paper from inside the printer as needed.
(See "Top Cover (Inside).")
b. Ejection Guide
Guides printed documents as they are ejected. Open this guide when loading a roll.
c. Roll Holder Slot
Slide the Roll Holder into this slot.
iPF825
→P.696
Printer Parts
>
Printer parts
>
Front
9
693
